2. SPECIFICATIONS

2.1 Model Number: Serial Numbers 220,000 & Higher: TR23KC

2.2 ENGINE

2.2.1 Engine Specifications: See your engine owners manual.
2.2.2 3600 RPM (No Load)

2.3 FUEL SYSTEM

2.3.1 Capacity: 5.0 gal. (18.9 L.)
2.3.2 Type of Fuel: Regular unleaded gasoline 87 octane or higher. In countries
using the research method, it should be a 90 octane minimum.
2.3.3 Fuel Filter: Replaceable in-line
2.3.4 Fuel Shut-Off Valve: 1/4 turn

2.4 ELECTRICAL SYSTEM

2.4.1 Charging System: Flywheel alternator
2.4.2 Charging Capacity: 15 amp Kohler Engine
2.4.3 Battery Type: BCI Group U1, 235 amps at 0 F
2.4.4 Battery Voltage: 12 Volt Polarity: Negative ground
2.4.5 Fuses: 20, and 30 amp blade type, 20 amp to charging circuit; 20 amp to
electric clutch; 30 amp to electro-mechanical actuator.
2.4.6 Safety Interlock System: Operator must be positioned in the seat with PTO
disengaged and brake engaged to start engine. Operator must be in seat
when PTO is engaged or when brake is disengaged or the engine will stop.

2.5 OPERATOR CONTROLS

2.5.1 Steering Control: Aircraft-style steering yoke.
2.5.2 Motion Control: Single foot pedal operated by the right foot. Provides forward
and reverse speed control with little effort. Motion control pedal and linkages
are protected by the motion override device when the parking brake is engaged.
2.5.3 Parking Brake Lever: Engages park brake and locks drive system in neutral.
Neutral lockout system prevents accidental engagement of drive system when
park brake is engaged and protects hydro-transaxle from potential damage.

2.6 SEAT

2.6.1 Type: high back, foam padded (internal suspension) with standard arm rests.
2.6.2 Mounting: Attached to activate a seat switch and attached to a seat spring for
maximum comfort over rough terrain. Adjustable fore and aft.
2.6.3 Armrests: foam padded flip-up armrests with height adjustment standard.
2.6.4 Seat Safety switch: Incorporated into the Safety Interlock System. Time
delay seat switch eliminates rough ground cut-outs.

2.7 HYDROSTATIC GROUND DRIVE SYSTEM

2.7.1 Hydrostatic transmission: Eaton 851 transaxle with 23:1 reduction ratio.
2.7.2 Hydrostatic direction control system is protected by a neutral lockout system.
2.7.3 Hydraulic Oil Type: Synthetic Mobil 1 15W-50
2.7.4 Hydraulic Oil Capacity: 8.5 qts. (8.0 L.)
2.7.5 Filter: Replaceable cartridge type
2.7.6 Speeds:
Exmark P/N 513211: 10 micron, 18 psi bypass
0 - 6.4 mph (10.2 km/hr) forward
0 - 3.2 mph (5.1 km/hr) reverse
