Epson Printer Instructions

Important Initial Ink Charging Instructions
1. Peel away the 3 pieces of tape and remove the spacer from the slip paper path.
2. Make sure the printer is on.
3. Open the roll paper cover and insert the roll paper; then close the cover.
4. Open the ink cartridge cover.
5. Take the new cartridge out of its packing and remove the yellow tape.
6. Note: You must not remove any tape on which the EPSON logo is printed.
7. Insert the cartridge firmly but gently as far as it will go until it clicks into place. For the two-
color model, you need to insert two separate ink cartridges.
8. Close the cover.
Note:
The printer takes about 1 minute to charge the ink. The POWER LED flashes during this
operation. Be sure not to turn off the power or open the printer cover while the POWER LED is
flashing.
When the initial ink charging is finished, the POWER LED stays on.
For full instructions, see the User's Manual.
Attaching the Feeder Guide
Feeding paper using the included feeder guide
allows you to insert a check straight. Also, the
auto sheet feeder (ASF) model printers can
feed up to 25 checks without manual feeding.
Follow these steps to attach the feeder guide.
1. Hold the edge of the feeder guide carefully.
2. Insert the dowels of the feeder guide into
the holes on the feeder guide; then move it
down until it stops in place.
Attaching the Pocket
A pocket is provided with each auto sheet
feeder (ASF) model printer. Follow the steps
shown below to attach the pocket.
1. Push down the pocket cover on the left of
the printer, and remove it.
Note:
To attach the cover again, insert the cover
while pushing it up.
2. Make sure that the ejection lever is open. If it is closed, open it.
The ejection lever is open.
Note:
Be careful not to hurt your fingers on the lever edge.
(only for the ASF model)
Dowel of the
feeder guide
The ejection lever is closed.
405075200
➀
➁
