Omron CPU Unit CJ2 Manual page 22

Performance Specifications
Item
Logical Ports for Logical Ports
Communications
Extended Logical Ports
Cip Class 3
Communications (Number of Connections)
Specification
UCMM
(Non-connection Type)
Peripheral (USB) Port
Baud Rate
Transmission Distance
Serial Port
Communications Method
Synchronization Method
Baud Rate
Transmission Distance
EtherNet/IP Port
Media Access Method
Modulation
Transmission Paths
Baud Rate
Transmission Media
Transmission Distance
Number of Cascade Connections
CIP Communications: Tag Data Links
Number of Connections
Packet Interval (Refresh period)
Permissible Communications Band
Number of Tag Sets
Type of Tags
Number of Tags per Connection
Maximum Link Data Size per Node
Maximum Data Size per Connection
Number of Registrable Tag Set
Maximum Tag Set Size
Maximum Number of Tags Refreshable in
a Single Cycle of CPU Unit (See note 3.)
Data Size Refreshable in a Single Cycle
of CPU Unit (See note 3.)
Change of Tag Data Link Parameter
Settings during Operation
Multi-cast Packet Filter (See note 5.)
CIP Communications: Explicit Messages
Class 3 (Number of Connections)
UCMM (Non-connection Type)
CIP Routing
FINS Communications
FINS/UDP
FINS/TCP
EtherNet/IP Conformance Test
EtherNet/IP Interface
Note 1. "Packets per second" is the number of communications packets that can be processed per second.
2. Large Forward Open (CIP optional specification) must be supported in order for 505 to 1,444 bytes to be used as the data size. Application is supported between CS/CJ-series PLCs.
When connecting to devices from other manufacturers, make sure that the devices support the Large Forward Open specification.
3. If the maximum number is exceeded, refreshing will require more than one CPU Unit cycle.
4. When changing parameters, however, the EtherNet/IP port where the change is made will be restarted. In addition, a timeout will temporarily occur at the other node that was
communicating with that port, and it will then recover automatically.
5. The EtherNet/IP port supports an IGMP client, so unnecessary multicast packets are filtered by using a switching hub that supports IGMP snooping.
22
CPU64-EIP CPU65-EIP
8 ports (Used for SEND, RECV, CMND, PMCR, TXDU, and RXDU instructions.)
64 ports (Used for SEND2, RECV2, CMND2, and PMCR2 instructions.)
Number of connections: 64
Maximum number of clients that can communicate at the same time: 32
Maximum number of servers that can communicate at the same time: 40
USB 2.0-compliant B-type connector
12 Mbps max.
5 m max.
Interface: Conforms to EIA RS-232C.
Half-duplex
Start-stop
0.3, 0.6, 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, or 115.2 (kbps)
15 m max.
—
CSMA/CD
Baseband
Star
100 Mbps (100Base-TX)
Shielded twisted-pair (STP) cable; Categories: 5, 5e
100 m (between hub and node)
No restrictions if switching hub is used.
—
256
0.5 to 10,000 ms (Unit: 0.5 ms)
Can be set for each connection. (Data will be refreshed at the set interval, regardless of the number of nodes.)
6,000 pps (See note 1.)
256
CIO, DM, EM, HR, and WR
8 (Seven tags if PAC status is included in the segment.)
184,832 words
252 or 722 words (See note 2.)
(Data is synchronized within each connection.)
256 (1 connection = 1 segment)
722 words (One word is used when PAC status is included in the segment.)
Output/send (CPU Unit to EtherNet/IP): 256
Input/receive (EtherNet/IP to CPU Unit): 256
Output/send (CPU to EtherNet/IP): 6,432 words
Input/receive (EtherNet/IP to CPU): 6,432 words
OK (See note 4.)
OK
—
Number of connections: 128
Maximum number of clients that can communicate at the same time: 32
Maximum number of servers that can communicate at the same time: 32
OK (CIP routing is enabled for the following remote Units: CJ1W-EIP21 and CJ2H-CPU6 -EIP.)
—
OK
16 connections max.
Conforms to A5.
10Base-T/100Base-TX
Auto Negotiation/Fixed Setting
CJ2H-
CPU66-EIP CPU67-EIP CPU68-EIP
