Craftsman 917.272200 Owner's Manual

25.0 hp electric start 46" mower automatic lawn tractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
CRI:IFTZMAN °
25.0 HP
ELECTRIC
START
46" MOWER
AUTOMATIC
LAWN TRACTOR
Model No.
917.272200
• Safety
• Assembly
• Operation
• Maintenance
• Repair Parts
CAUTION:
Read and follow all
Safety Rules and Instructions
before operating this equip-
ment.
For answers to your questions
about this product, Call:
1-800-659-5917
Sears Craftsman Help Line
5 am - 5 pm, Mon - Sat
Seam, Roebuck and Co., Hoffman Estates, IL 60179
Visit our Craftsman website: w_w_.sears.conVcreftsman

Advertisement

Table of Contents
loading

Related Manuals for Craftsman 917.272200

Summary of Contents for Craftsman 917.272200

  • Page 1 Call: Read and follow all 1-800-659-5917 Safety Rules and Instructions Sears Craftsman Help Line before operating this equip- 5 am - 5 pm, Mon - Sat ment. Seam, Roebuck and Co., Hoffman Estates, IL 60179 Visit our Craftsman website: w_w_.sears.conVcreftsman...
  • Page 2 Sears will replace the battery at no charge. Warranty ser- vice is available free of charge by taking your Craftsman riding equipment to your nearest Sears Service Center. In-home warranty service is available but a trip charge will apply.

  • Page 3: General Operation

    IMPORTANT: T his cuttingmachine SLOPE OPERATION is ca- pable of amputating hands and feet and Slopes are a major factor related to loss- throwing objects. Failure to observe the of-control and tipover accidents, which following safety instructions could result can result in severe injury or death. All in serious injury or death.
  • Page 4 Never run a machine inside a closed • Keep children out of the mowing area area. and under the watchful care of another Keep nuts and bolts, especially blade responsible adult. attachment bolts, tight and keep equip- • Be alert and turn machine off if children ment in good condition.

  • Page 5: Customer Responsibilities

    (Section 4442 of the Cali- CONGRATULATIONS on your purchase fornia Public Resources Coda). Other of a Craftsman Tractor. It has been de- states may have similar laws. Federal signed, engineered and manufactured to laws apply on federal lands. A spark at-...
  • Page 6 Steering Wheel Steering Sleeve Steering Extension Wheel Insert Steering Sleeve Seat (1) Washer (1) Shoulder 17/32 x 1-3/16 x 12 Gauge Bolt 5/16-18 _(1) Knob Mower Front Link Asse_ (4) Retainer Springs (single loop) (3) Retainer Springs (double loop) € (2) Keys Video Slope Sheet...
  • Page 7 Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your trac- tor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness.
  • Page 8 INSTALLSEAT TO DRIVE TRACTOR OFF SKID Adjustseat beforetighteningadjustment (See Operation section for location knob. controls) and function • Remove adjustment knob and flat WARNING: Before starting, read, un- washer securing seat to cardboard derstand and follow all instructions in the packing and set aside for assembly of Operation section of this manual.
  • Page 9 • Place front of mulcher plate over front IMPORTANT: For shipping purposes, the of mower deck opening and slide into mulcher plate was preattached to your place, as shown. mower. The mutcher plate must only be • Hook front latch into hole on front of used with the mulching blades that came mower deck.
  • Page 10 • Turn height adjustment knob clockwise • Install one front link in top hole of the R.H. front mower bracket and R.H. front to remove slack from mower suspen- sion. suspension bracket. Retain with two • Raise mower to highest position. single loop retainer springs as shown.

  • Page 11: Important Items

    CHECKLIST BEFORE YOU OPERATE AND ENJOY YOUR NEW TRACTOR, WE WISH TO ASSURE THAT YOU RECEIVE THE BEST PERFORMANCE AND SATISFAC- TION FROM THIS QUALITY PRODUCT. PLEASE REVIEW THE FOLLOWING CHECKLIST: All assembly instructions have been completed. / No remaining loose parts in carton. / Battery is properly prepared charged.
  • Page 12 Thesesymbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. BATTERY CAUTION OR REVERSE FORWARD FAST SLOW WARNING ENG,NE_j_ON _IENG'NEOFF O,L_PRESSURE L.GNTS_ON O%T_.P_ FUEL CHOKE MOWER HEIGHT PARKING BRAKE UNLOCKED MOWER LIFT LOCKED R N H L ATTACHMENT...

  • Page 13: Height Adjustment

    KNOWYOURTRACTOR READTHISOWNER'SMANUALAND SAFETYRULESBEFOREOPERATING YOUR TRACTOR Comparethe illustrationswith yourtractorto familiarizeyourselfwith the locations of various controls and adjustments. Save this manual for future reference. Light Switch Posi_on Ignition Ammeter Switch Choke Control Attachment Clutch Switch Throttle Control Lift Lever Plunger Clutch/Brake Control Attachment Lift Lever Height...
  • Page 14 The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses | or eye shields while operating your tractor or performing any adjustments or repairs. We recommend a wide vision safety mask over spectacles, standard safety glasses.
  • Page 15 The cutting height range is approximately • Start mower blades by engaging at- tachment clutch control. 1-1/2" to 4". The heights are measured from the ground to the blade tip with the • TO STOP MOWER BLADES - disen- engine not running. These heights are gage attachment clutch control.
  • Page 16 WARNING: Experience indicates that • Do not push or tow tractor at more than alcohol blended fuels (called gasohol or two (2) MPH. using ethanol or methanol) can attract • To reengage transmission, reverse moisture which leads to separation above procedure. NOTE: To protect hood from damage formation of acids during storage.
  • Page 17 PURGE TRANSMISSION WARM WEATHER STARTING (50 ° F and _lb CAUTION: Never engage or disen- above) gage freewheel lever while the engine is • When engine stads, slowly push choke running. control in until the engine begins to run To ensure proper operation and perfor- smoothly.
  • Page 18 MULCHING MOWING TIPS IMPORTANT: For best performance, keep MOWING TIPS mower housing free of built-up grass and • Tire chains cannot be used when the trash. Clean after each use. mower housing is attached to tractor. • The special mulching blade will recut •...

  • Page 19: General Recommendations

    FILL IN DATES _li_._//_._X'O_/,_/_'/_/_J MAINTENANCE SCHEDULE __J'_ AS YOU COMPLETE _"_Y _'_ _ ____'_ ATES R EGULAR SERVICE Check BrakeOperation Check "11re Pressure _1_/ Check OperatorPresence and InterlockSystems Check for Loose Fasteners SharpeNFlep;ace Mower Blades ,_,=c. " Check Battery Level Clean Batteryand Terminals Check Transaxle Cooling AdjustBlade Belt(s)Tension...

  • Page 20: Operator Presence System

    TRACTOR • Tighten bolt securely (27-35 Ft. Lbs. torque). Always observe safety rules when per- IMPORTANT: Blade bolt is Grade 8 heat forming any maintenance. treated. BRAKE OPERATION Trailing E Mandrel If tractor requires more than six (6) feet stopping distance at high speed in high- est gear, then brake must be adjusted.
  • Page 21 TO CLEAN BATTERY AND TERMINALS NOTE: Although multi-viscosity oils (5W30, 10W30 etc.) improve starting in Corrosion and dirt on the battery and ter- cold weather, these multi-viscosity oils minals can cause the battery to "leak" will result in increased oil consumption power.

  • Page 22: Engine Oil Filter

    CLEAN AIR INTAKE/COOLING AREAS TO SERVICE PRE-CLEANER • Wash it in liquid detergent and water. To insure proper cooling, make sure the • Squeeze it dry in a clean cloth. grass screen, cooling fins, and other ex- • Saturate it in engine oil. Wrap it in ternal surfaces of the engine are kept clean at all times.
  • Page 23 CLEANING We do not recommend using a garden • Clean engine, battery, seat, finish, etc. hose to clean your tractor unless the elec- of all foreign matter. trical system, muffler, air filter and carbure- • Keep finished surfaces and wheels free tor are covered to keep water out.
  • Page 24 TO LEVEL MOWER HOUSING • Before making any necessary adjust- ments, check that both front links are Adjust the mower white tractor is parked equal in length. Both links should be on level ground or driveway. Make sure approximately 10-3/8". tires are properly inflated (See =PROD- •...
  • Page 25 • Be sure spring is securely hooked to TO REPLACE MOWER DRIVE BELT primary idler arm and bolt in mower MOWER DRIVE BELT REMOVAL housing. • Park tractor on a level surface. Engage MOWER DRIVE BELT INSTALLATION parking brake. • Install belt in both idlers. Make sure •...
  • Page 26 TO REPLACE MOWER BLADE DRIVE • Check secondary idler arm and idler to BELT see that they rotate freely. • Be sure spring is hooked in secondary Park the tractor on level surface. Engage parking brake, idler arm and sway-bar bracket.
  • Page 27 TO REPLACE MOTION DRIVE BELT while motion control lever is in neutral po- sition, follow these steps: Park the tractor on level surface. Engage • Loosen the adjustment bolt. parking brake. For assistance, there is a • Move the motion control lever 1/4 to 1/2 belt installation guide decal on bottom side of left footrest.
  • Page 28 REPLACING BATrERY Washers CAUTION: Do not short battery termi- Retaining fBrf_ nals by allowing a wrench or any other Ring object to contact both terminals at the same time. Before connecting battery, re- move metal bracelets, wristwatch Axle/Cover "_Squara bands,rings,etc. (Rear Wheel Only) Positive terminal must be connected first TO START ENGINE...

  • Page 29: Interlocksand Relays

    INTERLOCKSAND RELAYS • Check that swivel is against stop. If it is not, loosen cable clamp screw and pull Loose or damaged wiring may cause your tractor to run poody, stop running, or pre- cable back until swivel is against stop. vent it from starting.
  • Page 30 Swivel PRELIMINARY SE-I-FING - • Be sure you have a clean air filter, and the throttle control cable and choke are adjusted properly (see above). Cable • With engine offturnidlemixturescrew in (clockwise) closing it finger tight Stop and then turn out (counterclockwise) Spring Governed Idle 1-1/4 to 1-1/2...
  • Page 31 Immediately prepare your tractor for stor- Also, experience indicates that alcohol age at the end of the season or if the trac- blended fuels (called gasohol or using tor will not be used for 30 days or more. ethanol or methanol) can attract moisture which leads to separation and formation...

  • Page 32: Troubleshooting Chart

    TROUBLESHOOTING CHART PROBLEM CAUSE CORRECTION • Fill fuel tank. Will not start • Out of fuel. • See "TO START ENGINE" in • Engine not "CHOKED" properly. Operation section. • Wait several minutes before at- • Engine flooded. tempting to start. •...
  • Page 33 TROUBLESHOOTING CHART PROBLEM CAUSE i CORRECTION Loss of power (cont'd) • Faulty spark plug. • Clean and rogap or change spark plug. • Dirty fuel filter. • Replace fuel filter. • Stale or dirty fuel. • Drain fuel tank and refill with fresh gasoline.
  • Page 34 TROUBLESHOOTING CHART CAUSE CORRECTION PROBLEM Poor grass discharge • Worn, bent or loose blade. • Replace/sharpen blade. (cont'd) Tighten blade bolt. • Clean underside of mower • Buildup of grass, leaves and trash under mower. housing. • Mower drive belt worn. •...
  • Page 35 TRACTOR -- MODEL NUMBER 917.272200 SCHEMATIC AMMETER WHITE OPERATOR PRESENCE RELAY #1 FUEL (OPTIONAL) IGNITION PLUGS GAP SPARK • UNIT (2 PLUGS ON TWIN CYL ENGINES) FUEL SHUT-OFF SOLENOID WIRING INSULATED CUPS NOTE: IF WIRING INSULATED CLIPS WERE REMOVED FOR SERVICING OF UNIT.
  • Page 36 TRACTOR - - MODEL NUMBER 917.272200 ELECTRICAL 27 14...
  • Page 37 FUSS 73510400 Nut Keps Hax 1/4-20 UNC 145491 Cabio, Ground 160784 Switch, Seat 163968 Switch, Ignition 140403 Key, Molded, Craftsman 170233 Harness, Ignition 131563 Cover, Terminal 145673 Solenoid 122822X Ammeter Rectangular 15 Amp 169416 Switch Pro 3 Pdt Red Delta...

  • Page 38: Chassisand Enclosures

    TRACTOR - - MODEL NUMBER 917.272200 CHASSISAND ENCLOSURES...
  • Page 39 TRACTOR -- MODEL NUMBER 917.272200 CHASSIS AND ENCLOSURES PART DESCRIPTION 169830 Chassis 169061 Dmwbar 17060612 Screw, 3/6-16 x 3/4 163976 Dash STD533710 Bolt, Carriage 3/8-16 x 1 167203 Panel, Dash, LH 167202 Panel, Dash, RH 161023X558 HoodAssembly 162026 Plate Battery STYT 19131312 Washer 13/32 x 13/16 x 12 Gauge STD541437...

  • Page 40: Ground Drive

    TRACTOR -- MODEL NUMBER 917.272200 GROUND DRIVE...
  • Page 41 TRACTOR - - MODEL NUMBER 917.272200 GROUND DRIVE PART PART DESCRIPTION DESCRIPTION ..Transaxle (See Breakdown) 140294 V-Belt, Ground Drive Hydro gear Model 314-0510 169691 Keeper, Center Spen 165866 Rod Shift Fender Adjust Lt 17060612 Screw 3/8-16 x 3/4 137140 Clutch E!ec Cvx 8883R Cover, Pedal...

  • Page 42: Steering Assembly

    TRACTOR - - MODEL NUMBER 917.272200 STEERING ASSEMBLY ..: : :.L-:--_-: :.,...
  • Page 43 TRACTOR - - MODEL NUMBER 917.272200 STEERING ASSEMBLY PART DESCRIPTION 159944X428 Steering Wheel 154427 Axle Assembly STMP Dropped STL 169840 Spindle Assembly, LH. 169839 Spindle Assembly, R.H. 6266H Bearing, Race, Thrust, Hardened 121748X Washer 25/32 x 1-5/8 x 16 Gauge 19272016 Washer 27/32 x I-1/4 x 16 Gauge 12000029...
  • Page 44 TRACTOR -- MODEL NUMBER 917.272200 ENGINE "81 OPTIONAL EQUIPMENT 1 Spark Arrester...
  • Page 45 TRACTOR -- MODEL NUMBER 917.272200 ENGINE PART DESCRIPTION 164O67 Control, Thmtlla Engine, (See Breakdown) B&S Model Number 445777-0129-E1 149723 Muffler 159955 Tube, Manifold, LH 160589 Tube, Manifold, RH 150176 Bolt 5/16-18 UNC x 3/4 w/Sems 162797 Shield,Browning 16.5391 Muffler Gasket (See Engine Breakdown) 13280336 Nipple, Pipe 3/8 NPTx4-1/2 13200300...

  • Page 46: Seat Assembly

    TRACTOR -- MODEL NUMBER 917.272200 SEAT ASSEMBLY PART PART DESCRIPTION DESCRIPTION 140124 Seat 72050412 Bolt, Carriage 1/4-20 x 1-1/2 140551 Bracket, Pivot, Seat 121249X Spacer, Split 71110616 Bolt 123740X Spring 19131610 Washer 13/32 x 1 x 10 Gauge 123976X Locknut, Flange 1/4 Grade 5 145006 Clip, Push-In Hinged 124238X...

  • Page 47: Wheels And Tires

    172055 Decal Dash Pnl 138311 Decal, LiftHandle Pad FootrestLH STLT 166887 Decal, Deck Mower EZ3 165800X428 163204 Decal, Fender, Craftsman 165799X428 Pad Footrest RH STLT 156439 Decal, By Pass Lt Hydro Decal, Fender Danger 169210 146046 Decal, V-Belt Drive Schematic...

  • Page 48: Lift Assembly

    TRACTOR - - MODEL NUMBER 917.272200 LIFT ASSEMBLY...
  • Page 49 TRACTOR -- MODEL NUMBER 917.272200 LIFT ASSEMBLY PART DESCRIPTION 159461 Lift Lever Inner Wire Assembly 159476 Shaft Assembly, Lift 138284 Pin. Groove 12000002 E-Ring 19211621 Washer 21/32 x 1 x 21 Gauge 120183X Bearing, Nylon 125631X Grip, HaP, d is, Fluted 122365X Button, Plunger, Red 139865...

  • Page 50: Mower Deck

    TRACTOR -- MODEL NUMBER 917.272200 MOWERDECK...
  • Page 51 TRACTOR - - MODEL NUMBER 917.272200 MOWER DECK PART PART DESCRIPTION DESCRIPTION Deck Weldment. 46" 137273 156948X608 Spring, Secondary 44/46/50 Vent 138457 Bracket Asm., Sway Bar Screw 3/8-16 x 1-1/4 STD624008 Retainer Spring 17060620 Spacer, Retainer 130832 Arm, Suspension, Rear 122052X (SwayBar) 144949X608...
  • Page 52 TRACTOR - - MODEL NUMBER 917.272200 HYDRO GEAR TRANSAXLE - - MODEL NUMBER 314-0510...
  • Page 53 TRACTOR -- MODEL NUMBER 917.272200 HYDROGEARTRANSAXLE - - MODEL NUMBER 314-0510 KEY PART PART DESCRIPTION DESCRIPTION Rotor, Brake 170351 Main Housing, Assembly 170408 Brake Puck 170352 Side Housing, Assembly 142883 Puck Plate 170353 Center Section, Assembly 142881 Brake Actuating Pin 170354 Swashplate, Trunion...
  • Page 54 TRACTOR - - MODEL NUMBER 917.272200 BRIGGS & STRATON ENGINE-MODEL NUMBER 445777, TYPE NUMBER 0129-E1 188'_ 265_ __-J_J 304 _r'r-_ r_-_-_, 102___ 5_85 t842_ 70_4_ "_1461 .447 147_' "_,mm._- 447A_ 122_ 51A_ 449_ 447A 1o17 524 Q 252[ 54 _ 654 _ 250 _ 1027 D...
  • Page 55 TRACTOR - - MODEL NUMBER 917.272200 BR|GGS & STRATON ENGINE-MODEL NUMBER 445777, TYPE NUMBER 0129-.E1 1022 _-_=7._ °,_ lO2, 387 _<_ 628" 163_------_ 418_--_-_ 918 J_ 121CARBURETOR _231 I 672_ 11131 _ 1123_ 276@ 104_ 552A6 1124_ los_ s33_ 987_ 1123_L_ - 13"'7_ "==_ _ I...
  • Page 56 TRACTOR - - MODEL NUMBER 917.272200 BRIGGS& STRATONENGINE-MODEL NUMBER445777,TYPE NUMBER0129-E1 729 _ 63s_ 358 GASKET SET 51A_ 868_ _, 943 C ) _(_1_ 1022_...
  • Page 57 TRACTOR - - MODEL NUMBER 917.272200 BRIGGS& STRATONENGINE-MODEL NUMBER445777,TYPE NUMBER0129-E1 PART PART DESCRIPTION DESCRIPTION 694001 Cylinder Assembly 130 690993 Throtlle Valve 499585 Bushing/Seal Kit 131 499805 Throttle Shaft Kit 391086 Oil Seal 133 499806 Carburetor Float 690069 En._ine Sump 135 499803 Fuel Transfer Tube 499587 Cylinder Head (Cylinder #1)
  • Page 58 TRACTOR - - MODEL NUMBER 917.272200 BRIGGS& STRATONENGINE-MODEL NUMBER445777,TYPE NUMBER0129-E1 KEY PART KEY PART DESCRIPTION DESCRIPTION Air Guide Cover 808656 Fuel Pump 865B 691015 *V Valve Seal 690442 Washer (Governor Crank) 690968 Guide Bushing 94930 Screw (Back Plate) 690969 Alternator Connector Wire 690999 Carburetor Plate 399916...
  • Page 59 SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION ONLY RIDE UP AND DOWN HILL, NOT ACROSS HILL SIGHTING GUIDE greater than 15°), never across the face. Make turns gradu- ally to prevent tipping or loss of control. Exercise extreme caution when changing direction on slopes. Operate your Tractor up and down the face of slopes (not...
  • Page 60 For repar of major _ al:Ol_'_nces in your own home... no rnaP, e r who made it, no matter who sotd it! 1-800-4-MY-H OME %_n_ (_o_n_ht (1-800-469-4663) www.letlrl,¢Ol_ To bringin poducts suchasvacuun's,lawnequipmenta_d electr_ics for repair,callfor the IocatJon o f your nearestSears Parts & Repair Center 1-800-488-1222 A,v_ _=r_ WWW.INIQI1Lconl...
