- Page 1 INTERNAL REWINDER-DISPENSER INSTALLATION GUIDE For printer models: 4xxe Series Read this Installation Guide before and during the installation of the above accessory. Keep this Installation Guide handy for future reference.
-
Page 2: Limitation Of Liability
1 General 1.1 Important information This quick guide provides important information on how to setup your new SATO product. Be sure to read this quick guide thoroughly before using this printer. It is an integral part of the product and should be kept in the immediate vicinity of the device and available to the operating staff. -
Page 3: Explanation Of Symbols
1.3 Explanation of symbols This instruction manual uses various warning icons to help you understand the safe operation of your printer. Explanations of the icons are below. WARNING! Indicates neglectful or erroneous use may cause irreparable damage to the product, serious injury to the operator, or worse. -
Page 4: Sato Group Of Companies
Contact and Document Information SATO GROUP OF COMPANIES International Headquarters Americas SATO INTERNATIONAL PTE. LTD SATO INTERNATIONAL AMERICA, INC. 438A Alexandra Road #05-01/04, (Regional HQ) Alexandra Technopark, Singapore 119967 10350 Nations Ford Road Suite A, Charlotte, NC 28273 Phone: 65-6271-2122 Fax : 65-6271-2151 Email: sales@sato-int.com Phone: 1-704-644-1650 Fax: 1-704-644-1662 Email: satosales@satoamerica.com... - Page 5 GL4xxe Internal Rewinder-Dispenser Installation The installation procedure for the Internal Rewinder with front-mounted dispenser, involves three major steps, that are similar to the installation of the GL4xxe internal rewinder: 1) Removing the base of the printer. 2) Mounting the printer above the rewinder and reinstallation of all removed covers. 3) Mechanical adjustment of the rewinder.
- Page 6 1) Removing the base of the printer (cont’d) The front cover can now be removed. Figure 1c. Front cover can now be removed Remove the lock shaft located at the front of printer. (Do not lose this part as it is essential for the installation of dispenser option) Note This lock shaft must be removed for the...
- Page 7 1) Removing the base of the printer (cont’d) The fifth screw to be removed is shown here. Figure 1e. Removing the fifth of nine screws The sixth and seventh screws are shown here, securing the base to the front of the chassis.
- Page 8 1) Removing the base of the printer (cont’d) Finally, carefully separate the base plate of the printer from the main chassis. This can be done by placing the printer on its side and pulling the base plate out. Figure 1h. Separating the base from the printer...
- Page 9 Mounting the printer above the rewinder-dispenser To facilitate easier mounting, it is ﾌﾛﾝﾄｶﾊﾞｰ Front cover recommended that you remove the front cover of the internal rewinder-dispenser beforehand. Pull down the side cover of the internal rewinder and remove two bind screws (M4x4) located as shown within the orange circles.
- Page 10 Mounting the printer above the rewinder A total of seven screws (cross recessed hexagonal bolt M4x10) are used to install the internal rewinder-dispenser to the printer chassis (Do not damage the PCB when using any tool such as screwdriver) Do not tighten all seven screws until you are sure the installation alignment is correct.
- Page 11 Mounting the printer above the rewinder (cont’d) If the front cover snaps into place correctly, you can proceed to further tighten the screws permanently, followed by inserting the thumbscrew used to secure the printer’s front cover in the first step of this guide. Figure 2g.
-
Page 12: Advanced Mode
3) Mechanical adjustment of the dispenser Turn the printer ON and take it OFFLINE (by ADVANCED MODE pressing the LINE button). Use the Media Go into the printer’s ADVANCED Mode and Handling scroll to the Media Handling menu. Select menu to Peel-Off to activate the peel-off and rewinder activate the rewinder...
