- Page 1 RFID KIT INSTALLATION GUIDE For printer models: 4XXe Series For printer models: Read this Installation Guide before and during the installation of the above accessory. Keep this Installation Guide handy for future reference.
-
Page 2: Limitation Of Liability
General 1.1 Important information This quick guide provides important information on how to setup your new SATO product. Be sure to read this quick guide thoroughly before using this printer. It is an integral part of the product and should be kept in the immediate vicinity of the device and available to the operating staff. -
Page 3: Explanation Of Symbols
1.3 Explanation of symbols This instruction manual uses various warning icons to help understand safe operation your printer. Explanations of the icons are below. WARNING! Indicates neglectful or erroneous use may cause irreparable damage to the product, serious injury to the operator, or worse. CAUTION! Indicates a specific point where caution should be used. -
Page 4: Sato Group Of Companies
Contact and Document Information SATO GROUP OF COMPANIES International Headquarters Americas SATO INTERNATIONAL PTE. LTD SATO INTERNATIONAL AMERICA, INC. 438A Alexandra Road #05-01/04, (Regional HQ) Alexandra Technopark, Singapore 119967 10350 Nations Ford Road Suite A, Charlotte, NC 28273 Phone: 65-6271-2122 Fax : 65-6271-2151 Email: sales@sato-int.com Phone: 1-704-644-1650 Fax: 1-704-644-1662 Email: satosales@satoamerica.com... - Page 5 GL4xxe RFID KIT Installation The complete RFID kit for the GL consists of five (5) parts: Four parts from the main RFID kit and one part containing the RFID Reader module from AWID. All five parts must be available before installation. Installation involves five (5) steps: Removing the covers;...
- Page 6 Removing the front cover Tool(s) required Flat blade screwdriver (recommended) Loosen and remove the thumbscrew fastener that secures the front cover. Figure 1a. Removing the thumbscrew Pull the outer edge of the front cover outwards, and then push the entire cover in the direction shown by the arrow.
- Page 7 Removing the Print Head Release the print head assembly by turning the head lock latch counterclockwise. Press the spring-loaded tab as indicated here, to release the print head. Disconnect the data and power cables from the print Figure 2a. head. Turning the head lock latch Set the print head aside for now.
- Page 8 Installing the antenna Part(s) Required ANTENNA ASSY, RFID, SL4M SCREW, 6-19 HL X 1/2, PHCR, SS410, ANSI B18.6.4 Tool(s) required #1 Phillips + screwdriver - 12 in. lb Remove the gap sensor Figure 3a. paddle (circled red) by sliding Removing the gap sensor it out.
- Page 9 Assembling the Reader Module Antenna cable Parts required READER MOUNT SUBASSEMBLY, GL4xxe Tool(s) required #1 Phillips + screwdriver - 8 in. lb. Figure 4a. 1. Plug the antenna cable into the Ports on the Reader port on the right side of the Subassembly.
- Page 10 Reassembly Tools required #1 Phillips + screwdriver - 8 in. lb. Pull any slack interface cable slack back into the electronics compartment of the printer. Put back the side cover that was removed in Step 3 (page 6). Tighten and torque screws. Put back the front cover that was removed in Step 2.
