[6500]
Continuous ROM error
alternate
blinking
Alarm LED lit RAM error
*1: Before replacement of the logic board ass'y, check the waste ink amount (by service test print or
EEPROM information print). If the waste ink amount is 7% or more, also replace the ink absorber kit
(QY5-0152) when replacing the logic board ass'y.
[See Section 3-3. Adjustment / Settings, (5) Service mode, for details.]

2-3. Warnings

Printer (no LED indications):
Displayed warning
Low ink
Print head temperature rise
Protection of excess rise of the print
head temperature
*1: If the warning is displayed, the carriage does not move to the ink tank replacement position when the
access cover is opened.

2-4. Troubleshooting by Symptom

The power does not turn on.
The power turns off
immediately after power-on.
Faulty operation
A strange noise occurs.
Printing stops mid-way.
Multiple sheets feed.
Paper does not feed.
Paper feed
problems
Paper feeds at an angle.
- Logic board ass'y (QM2-2733)
- Logic board ass'y (QM2-2733)
- Status monitor indication.
- The ink tank lamp flashes slowly (at about a second interval).
If the print head temperature is high when the access cover is
opened, the warning is displayed
When the print head temperature falls, the warning is released.
If the print head temperature exceeds the specified limit, a Wait
is inserted during printing,
Symptom
1-9
Remarks
*1
.
Solution
Replace the
- AC adapter, or
*1
- logic board ass'y .
Remove foreign material, or attach a
removed part if any.
Replace the logic board ass'y
Replace the
- sheet feed unit, or
- cassette.
Remove foreign material, or replace
the
- sheet feed unit, or
- cassette.
Remove foreign material, adjust the
paper guide, or replace the
*1
*1
Remarks
*1
.
