Capturing images
4
Use the mode select buttons to choose the mode.
• Click
to capture images being displayed on the LCD
screen of the VIEWCAM.
• Click
to capture images recorded on a tape as the
tape is playing.
5
Use the edge smoothing AUTO or OFF button to select
whether or not to correct the image to be captured.
• When edge smoothing AUTO is selected, images are
automatically corrected when they are captured from
the VIEWCAM. We recommend normally selecting this.
• When edge smoothing OFF is selected, images are not
corrected when they are captured from the VIEWCAM.
On VIEWCAMS which automatically perform edge smoothing on
Note
images, the images are captured with the edge smoothened without
having to set this button.
6
Start to view, record or playback the tape on the
VIEWCAM to display images on its LCD screen.
• When capturing images being displayed on the LCD
screen, the zoom buttons (Camera mode) can be used
to enlarge or reduce the image you want to capture.
• When capturing images being played, use the control
buttons (VCR mode) to display the image you want to
capture.
CONTENTS
CONTENTS
7
Click
when the image you want to capture
is displayed.
• The image stops moving (a still image is displayed) and
transfer from the VIEWCAM begins.
• The save folder selection dialog box shown below is
displayed when transfer is completed.
• When the image capture has been completed, the
VIEWCAM returns to the status prior to the image
capture.
(Example: When the
playback, the playback will stop until the image receiving
has been completed, and then continue after.)
4
