HP StorageWorks 8B - FC Entry Switch User Manual page 118

4
Switch View
Figure 4-5
Following is a description of the fields on the SNMP tab:
Name
Location
Description
Trap Level
Enable Authentication
Trap
Community And Trap Recipient Configuration
Community String
4-46
SNMP Tab
Displays or sets contact information for switch. Default is Field
Support.
Displays or sets the location of switch. Default is End User Premise.
Displays or sets system description. Default is Fibre Channel Switch.
Sets severity level of switch events that prompt SNMP traps. Default
is 0.
Check on to enable authentication traps; uncheck to disable
(recommended).
Displays the community strings that are available to use. A
community refers to a relationship between a group of SNMP
managers and an SNMP agent, in which authentication, access
control, and proxy characteristics are defined. A maximum of six
community strings can be saved to the switch.
Web Tools User's Guide
