Jenn-Air JS42SEDUDB00 Parts List page 14

MOTOR AND ICE CONTAINER PARTS
For Model: JS42SEDUDB00
Illus.
No.
1 2222965 Ice Bin
2 W10151247 Crusher Bin
3 W10140642 Auger
4 2258220 Washer, Auger
5 1119007 Spacer, Flat (6)
6 2317248 Cover, Crusher
7 2257024 Blade, Rotary
8 1119005 Spacer, Step (2)
9 2257020 Blade, Fixed
10 2257023 Blade, Rotary
11 2317239 Block, Blade
12
13 2257022 Blade, Rotary
14
15 2198661 Washer, Coupling
16 2188918 Coupling, Top
17 8281164 Screw
18 3400065 Screw
19 2266800 Button, Bin
20 W10134783 Latch, Bin
21 2198608 Spring, Latch
22 2198671 Screw (2)
23 8281163 Screw
24 2188919 Holder
25 2198628 Seal
26 2318030 Drive Shaft
27 2318011 Enclosure, Motor
28 2315546 Dispenser, Motor
29 2318028 Cover
30 2315559 Sleeve. Coupling
31 2317250 Divider Chamber
32 2317243 Wiper
(Stainless Steel)
Part
No. DESCRIPTION
489229 Roll Pin
489235 Washer, Plain
14
W10180976
