DIRECT STEAM
COUNTERTOP
TILTING KETTLES
MODELS
K6DTT
ML-136070
K12DTT
ML-136071
For additional information on Vulcan-Hart or to locate an authorized parts and
service provider in your area, visit our website at www.vulcanequipment.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANEQUIPMENT.COM
INSTALLATION &
OPERATION MANUAL
3600 NORTH POINT BLVD.
BALTIMORE, MD 21222
FORM 37480 (02-11)
Advertisement
Table of Contents
Related Manuals for Vulcan-Hart K12DTT
Summary of Contents for Vulcan-Hart K12DTT
-
Page 1: Direct Steam
MODELS K6DTT ML-136070 K12DTT ML-136071 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanequipment.com VULCAN-HART 3600 NORTH POINT BLVD. DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC BALTIMORE, MD 21222 WWW.VULCANEQUIPMENT.COM... -
Page 2: Important For Your Safety
DIRECT STEAM COUNTERTOP TILTING KETTLES IMPORTANT FOR YOUR SAFETY THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL STEAM EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. -
Page 3: Table Of Contents
DIRECT STEAM COUNTERTOP TILTING KETTLES TABLE OF CONTENTS INSTALLATION, OPERATION AND MAINTENANCE OF K6DTT AND K12DTT DIRECT STEAM TILTING KETTLES ............4 GENERAL ........................... 4 UNPACKING ..........................5 INSTALLATION CODES AND STANDARDS ................5 LOCATION ..........................5 INSTALLATION ..........................5 INSTALLING K6DTT ON COUNTER OR STAND .............. -
Page 4: Installation, Operation And Maintenance Of K6Dtt And K12Dtt Direct Steam Tilting Kettles
INSTALLATION, OPERATION AND MAINTENANCE OF K6DTT AND K12DTT DIRECT STEAM TILTING KETTLES SAVE THESE INSTRUCTIONS FOR FUTURE USE GENERAL Vulcan countertop tilting kettles are produced with quality workmanship and material. Proper installation, usage and maintenance will result in many years of satisfactory performance. It... -
Page 5: Unpacking
15 days of delivery. stand. Place unit in a drained location. INSTALLATION CODES AND STANDARDS In the United States, Vulcan kettles must be installed in accordance with: State and local codes NFPA Standard NFPA-96, Vapor Removal... -
Page 6: Installing K12Dtt On Table Or Stand
DIRECT STEAM COUNTERTOP TILTING KETTLES 2. On countertop, drill two 1" holes on 8 " PLUMBING CONNECTIONS centers for the two kettle leg stanchions. Plumbing connections must comply with 3. Remove the mounting locknuts and applicable sanitary, safety and plumbing washers [ "... -
Page 7: Operation
DIRECT STEAM COUNTERTOP TILTING KETTLES OPERATION The kettle and its parts are 1. Fill kettle with product to the desired level. hot. Use care when operating, cleaning or 2. Slowly turn the steam control valve to the servicing the kettle. full open position. -
Page 8: Enemies Of Stainless Steel
DIRECT STEAM COUNTERTOP TILTING KETTLES With 12-30 percent chromium, an invisible lines are present, always scrub in a motion passive film covers the steel’s surface acting as parallel to the lines. When the grain cannot a shield against corrosion. As long as the film is be seen, play it safe and use a soft cloth or intact and not broken or contaminated, the metal plastic scouring pad. -
Page 9: Recommended Cleaners For Specific Situations
DIRECT STEAM COUNTERTOP TILTING KETTLES Recommended cleaners for specific situations CLEANING AGENT COMMENTS Routine cleaning Soap, ammonia, Apply with cloth or sponge detergent, Medallion Fingerprints & smears Arcal 20, Lac-O-Nu Ecoshine Provides barrier film Stubborn stains & Cameo, Talc, Zud, Rub in direction of polish lines discoloration First Impression... -
Page 10: Troubleshooting
DIRECT STEAM COUNTERTOP TILTING KETTLES TROUBLESHOOTING K6DTT & K12DTT: Direct Steam Countertop Kettle Troubleshooting SYMPTOMS POSSIBLE CAUSES/REMEDY Kettle not heating No steam supply/Turn on building supply valve to kettle. Boiler or steamer supplying kettle not on/Turn on unit. Building steam not turned on/Call building maintenance. Steam control valve closed/Open control valve to allow steam to enter kettle jacket. - Page 11 DIRECT STEAM COUNTERTOP TILTING KETTLES K6DTT & K12DTT: Direct Steam Countertop Kettle Troubleshooting (continued) SYMPTOMS POSSIBLE CAUSES/REMEDY Kettle stays hot after Valve seal has failed/Replace valve/Call an authorized servicer to repair. steam control valve Dirty supply steam/Replace valve, install steam strainer, is fully closed call authorized servicer.
-
Page 12: Service And Parts Information
DIRECT STEAM COUNTERTOP TILTING KETTLES SERVICE AND PARTS INFORMATION To obtain service and parts information concerning this model, contact the Vulcan-Hart Service Agency in your area (refer to our website, www.vulcanequipment.com for a complete listing of Authorized Service and Parts depots).
