ELECTRIC
TILTING
COUNTER KETTLES
MODELS
K6ETT
ML-136067
K12ETT
ML-136068
K20ETT
ML-136069
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
INSTALLATION &
OPERATION MANUAL
3600 NORTH POINT BLVD.
BALTIMORE, MD 21222
FORM 35455 (11-08)
Advertisement
Table of Contents
Related Manuals for Vulcan-Hart K12ETT
Summary of Contents for Vulcan-Hart K12ETT
- Page 1 K6ETT ML-136067 K12ETT ML-136068 K20ETT ML-136069 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM INSTALLATION & OPERATION MANUAL 3600 NORTH POINT BLVD.
-
Page 2: Important For Your Safety
ELECTRIC TILTING COUNTER KETTLES IMPORTANT FOR YOUR SAFETY THIS MANUAL HAS BEEN PREPARED FOR PERSONNEL QUALIFIED TO INSTALL ELECTRICAL EQUIPMENT, WHO SHOULD PERFORM THE INITIAL FIELD START-UP AND ADJUSTMENTS OF THE EQUIPMENT COVERED BY THIS MANUAL. alteration, service or maintenance can cause property damage, injury or death. -
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL ... 4 Unpacking ... 5 Installation Codes and Standards ... 5 INSTALLATION ... 5 Location ... 5 Minimum Clearance ... 5 Installing Electric Kettle on Counter ... 6 Installing Floor Mounted K20ETT ... 6 Electrical Connection ... 6 Electrical Specifications ... -
Page 4: General
The electric steam kettles are available in 6-, 12- and 20-gallon capacity models. TABLE 1. MODEL CHART Model Gallons Quarts Number K6ETT K12ETT K20ETT Fig. 1 K12ETT Electric Steam Kettle Liters Fig. 2 K20ETT Electric Steam Kettle — 4 —... -
Page 5: Unpacking
Canadian Standards Association, 5060 Spectrum Way, Mississauga, Ontario, Canada L4W 5N6 LOCATION The K6ETT and K12ETT tilting kettles are to be permanently mounted on a counter or a stand. The K20ETT is to be floor mounted. MINIMUM CLEARANCE TABLE 2. MINIMUM CLEARANCE... -
Page 6: Installing Electric Kettle On Counter
208V / 240V 308V / 480V K6ETT 7.5 kW-10kW K12ETT, 1 12 kW-16kW K20ETT K6ETT 7.5 kW-10kW K12ETT, 3 12 kW-16kW K20ETT Note: K6ETT and K12ETT have external terminal block. In K20ETT, terminal block is inside control box. — 6 — 7.5 kW 12 kW... -
Page 7: Operation
The kettle and its parts are hot. Use care when operating, cleaning or servicing the kettle. VENTING While the kettle is cold, check the vacuum/ pressure gauge. The gauge should be in the vacuum zone measuring between 25 to 30 in. Hg (84 to 100kPa). - Page 8 ELECTRIC TILTING COUNTER KETTLES TABLE 4. CONTROLS AND INDICATORS Item Tilt Handle Power ON/OFF Switch Power ON Indicator (Amber) Low Water Indicator (Red) Temperature Light (Amber) Thermostat Knob Vacuum Pressure Gauge Tilt Lock Mechanism Fig. 5 Kettle Controls Function Tilts kettle. Controls power to the kettle.
-
Page 9: Maintenance
CLEANING power to the machine and follow Lockout/Tagout procedures before cleaning. NOTE: Do not hose down under any condition. Failure to comply will void the warranty. The kettle interior and exterior should be washed after each use when a different food is to be cooked next or when cooking is completed for the day. -
Page 10: Troubleshooting
ELECTRIC TILTING COUNTER KETTLES K6ETT, K12ETT, K20ETT ELECTRIC COUNTERTOP KETTLE TROUBLESHOOTING SYMPTOMS Kettle not coming Power switch not turned on/Turn on kettle power switch. on, no power light. Kettle unplugged/Plug kettle in. Breaker tripped or turned off/Reset or turn breaker on. -
Page 11: Service And Parts Information
ELECTRIC TILTING COUNTER KETTLES SERVICE AND PARTS INFORMATION To obtain service and parts information concerning this model, contact the Vulcan-Hart Service Agency in your area (refer to our website, www.vulcanhart.com for a complete listing of Authorized Service and Parts depots). - Page 12 ELECTRIC TILTING COUNTER KETTLES (11-08) PRINTED IN U.S.A. — 12 —...
