2.1.2 STS
An STS object accumulates the following statistical information about an arbitrary 32-bit wide
data series: count, total, and maximum.
Statistics are accumulated in 32-bit variables on the target DSP and in 64-bit variables on the
host PC. When the host polls the target for real-time statistics, it resets the variables on the
target. This minimizes space requirements on the target, while allowing you to keep statistics for
long test runs.
As part of using the DSP/BIOS instrumented kernel, the application automatically acquires STS
information for HWI, PIP, PRD, SWI, and TSK objects. To use this built-in feature on TSKs, the
application must call the TSK_settime and TSK_deltatime APIs to obtain STS information.
Custom STS objects can also be created in the DSP/BIOS configuration. By using the STS APIs
for the created objects, you can determine what statistical information needs to be acquired by
the system application during run-time.
2.1.3 TRC
The TRC module manages a set of trace control bits that control the real-time capture of
program information through event logs and statistics accumulators. For greater efficiency, the
target does not execute log or statistics APIs unless tracing is enabled.
This module contains two user-defined TRC flags that can be toggled using the DSP/BIOS RTA
Control Panel in Code Composer Studio. The application can use these bits to enable or disable
sets of explicit instrumentation. The program can use the TRC_query API to check the settings
of these bits and either perform or omit instrumentation calls based on the result. DSP/BIOS
does not use or set these bits.
2.1.4 UTL
UTL is part of the Reference Frameworks distribution. The UTL module is used for debugging
and diagnostics.
The module is essentially a set of macros that can either be expanded to code that performs the
desired debugging function, or removed completely when building depending on the value of the
UTL_DBGLEVEL preprocessor flag. The UTL module encapsulates DSP/BIOS services such as
CLK, STS, and LOG in APIs. These services can be easily removed in the final build by using
the preprocessor flag, -d "UTL_DBGLEVEL=0".
With conditional expansion of macros to code you can reduce code size and remove
unnecessary functionality in the deployment phase without having to remove development
debugging/diagnostics aids. This technique also means you don't need to modify code at
deployment time, thus reducing the possibility of error.
