Oki C5300n Install Manual

Computer connections & software install guide
Hide thumbs Also See for C5300n:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, Configuration Manual
Computer Connections & Software Install Guide

Installation Checklist

Network Install: Hardware ..........................2
□
□
Network Install: Software ...........................3
• TCP/IP ...............................................................3
• Novell.................................................................6
Local Install: Windows USB Port...............7
□
• Computer Connection: Windows 98/Me ...........7
• Computer Connection: Windows 2000/XP .......8
• Software for Windows 98 ..................................9
• Software for Windows Me...............................11
• Software for Windows 2000 ............................13
• Software for Windows XP ...............................14
Local Install: Windows Parallel Port .......15
□
• Computer Connection ......................................15
• Software for Windows .....................................16
Macintosh Install: Hardware ....................18
□
• Network ...........................................................18
• USB..................................................................19
Macintosh Install: Software......................20
□
• OS 8.6 to 9.1 ....................................................20
• OS X.1 and X.2................................................22
C5300
USB Versus Parallel: Windows
Installation instructions are included for both USB and
parallel connections. Oki Data recommends using a USB
connection, as your printer is performance optimized for a
USB interface.
Printer Drivers Available
Which Printer Driver?
Your printer comes with Windows drivers for PCL and
Postscript. You can install either driver or both, depending
on your application.
When to Use the PCL Driver
If you use TrueType fonts and you do not print PostScript
graphics (including ".eps" files), choose the PCL driver.
This will be more efficient and give good results.
When to Use the Postscript Emulation
Driver
If you use PostScript fonts or you will be printing PostScript
graphics, choose the Postscript emulation driver.
Performance will be faster and graphics will be printed at
their best quality.
When to Install Both Drivers
If your applications vary, you could choose to install both
drivers, then select the one you plan to use most to be your
Windows default driver. Choose the alternate driver from
within the print dialog when you need to.
If you install both drivers, simply select the same printer
port (LPT1 or Network Port) during the installation.
Readme File
Please refer to the readme file on the Drivers CD
supplied with your printer for the latest information on
printer drivers.
1

Advertisement

Table of Contents
loading

Related Manuals for Oki C5300n

Summary of Contents for Oki C5300n

  • Page 1: Installation Checklist

    USB Versus Parallel: Windows Installation instructions are included for both USB and Network Install: Hardware ......2 □ parallel connections. Oki Data recommends using a USB connection, as your printer is performance optimized for a □ Network Install: Software ......3 USB interface.

  • Page 2: Network Install: Hardware

    Network Install: Hardware ® Note: No Ethernet cable is supplied with the printer. Use an Ethernet cable with two twisted wire pairs and an RJ45 plug. □ Turn off the printer. □ Remove the plug from the Ethernet port ( ), then connect your Ethernet cable to the port.

  • Page 3: Network Install: Software

    When the installation is complete, click Finish to □ Click Next. launch the Oki LPR utility. The Menu Installer window appears. Use the Oki LPR Utility to discover the printer: □ Click the Printer Driver Installer button. The Local or network printer screen appears. □...
  • Page 4 Network Install: Software TCP/IP (cont.) Network Client Distribution Configuring the Print Server via the Embedded Web Page If you are installing the software on a network for network clients, the software must be installed on all clients’ Note: For more detailed information, see the OkiLAN workstations.
  • Page 5 Network Install: Software TCP/IP (cont.) Activating the Duplex Unit, To Activate in the PCL Driver: Internal Hard Drive and Click Start → Settings → Printer. □ □ Second Paper Tray Options Right click the PCL printer icon, then click Properties (Windows 2000/XP/Me/9x), or Document Defaults (Windows NT 4.0).

  • Page 6: Launching The Utility

    The Menu Installer Software Installation screen Launching the Utility appears. □ Click the Network Software button. To launch the utility click Start → Programs → Oki Setup □ Utility → AdminManager. Click the Installation/Config button. □ Click the Admin Mgr / Quick Setup button.

  • Page 7: Local Install: Windows Usb Port

    Local Install: Windows USB Port Computer Connection: Windows 98/Me Note: No USB interface cable is supplied with the printer. Use a USB cable that is compatible with USB specification 1.1 or 2.0. • A USB interface will only operate using Windows 2000, Windows XP, Windows Me, and Windows 98. Windows 95 and NT 4.0 do not support USB.
  • Page 8 Local Install: Windows USB Port Computer Connection: Windows 2000/XP Note: No USB interface cable is supplied with the printer. Use a USB cable that is compatible with USB specification 1.1 or 2.0. • A USB interface will only operate using Windows 2000, Windows XP, Windows Me, and Windows 98. Windows 95 and NT 4.0 do not support USB.

  • Page 9: Software For Windows 98

    Choice (PCL or Postscript) Well □ With the Drivers CD still in your CD-ROM drive, click Note: If at any time during this procedure the OKI Menu Start → Run. Installer screen appears, click Cancel. □ Browse to your CD-ROM drive and click □...

  • Page 10: Install The Printer Software

    Local Install: Windows USB Port Software for Windows 98 (cont.) Install the Printer Software Activating the Duplex Unit, Utilities Internal Hard Drive and Second Paper Tray Options □ With the Drivers CD installed in your CD-ROM drive, click Start → Run → Browse. Browse to your If your printer has an optional duplex unit, internal hard CD-ROM Drive and double-click INSTALL.EXE.

  • Page 11: Software For Windows Me

    Local Install: Windows USB Port Software for Windows Me Install the Driver of Your To Install the Second Driver as Choice (PCL or Postscript) Well □ With the Drivers CD still in your CD-ROM drive, click □ Check that the USB cable is plugged in and the printer Start →...

  • Page 12: Install Printer Software Utilities

    Local Install: Windows USB Port Software for Windows Me (cont.) Install Printer Software Utilities □ With the Drivers CD installed in your CD-ROM drive, click Start → Run. Browse to your CD-ROM Drive and double-click INSTALL.EXE. Click OK. □ The License Agreement appears. Click Next. □...

  • Page 13: Software For Windows 2000

    Local Install: Windows USB Port Software for Windows 2000 Install the Driver of Your Note: When prompted to select a port, select LPT1 temporarily. Choice (PCL or Postscript) □ Click Finish. □ Check that the USB cable is plugged in and the printer When the installation is complete: is powered on.

  • Page 14: Software For Windows Xp

    Local Install: Windows USB Port Software for Windows XP Install the Driver of Your When the installation is complete: Click Start → Settings → Printers. □ Choice (PCL or Postscript) □ Right click the printer icon, then click Properties. □ Check that the USB cable is plugged in and the printer □...

  • Page 15: Computer Connection

    Local Install: Windows Parallel Port Computer Connection □ Turn off both the computer and the printer. □ Attach a standard IEEE-1284 parallel cable (not supplied) to the parallel port (1) on the printer, securing it with the spring clips. □ Attach the other end to the parallel port on the computer and secure it in place with the screws.

  • Page 16: Software For Windows

    Local Install: Windows Parallel Port Software for Windows Install the Driver(s), □ Select the driver you wish to install: • For the PCL driver, click OKI C5300(PCL) Windows 98/Me [drivers\parallel\win2k_xp\pcl\ok715.inf] □ Insert the Drivers CD supplied with your printer into •...

  • Page 17: Windows 2000

    Local Install: Windows Parallel Port Software for Windows (cont.) Install the Driver(s), Install the Driver(s), Windows 2000 Windows NT 4.0 (SR 6) Note: Two Postscript emulation drivers are available: Use the Add Printer Wizard. • An ECP-enabled driver (recommended), which □...
  • Page 18 Macintosh Install: Hardware Network ® Note: Requires Mac OS 8.6 or above, running on a Macintosh computer with EtherTalk interface. The Ethernet cable is not supplied with the printer. Use an Ethernet crossover cable with RJ45 connectors at either end. □...
  • Page 19 Macintosh Install: Hardware Note: No USB interface cable is supplied with the printer. Use a cable that is compatible with USB specification 1.1 or 2.0. • Requires Mac OS 9.04 or higher • Printer operation is not assured if another USB compatible device is connected concurrently with it. •...

  • Page 20: Install The Driver

    Macintosh Install: Software OS 8.6 to 9.1 Install the Driver Note: If you need to verify the printer name, press the print server test button (1) to print the Network □ Information configuration sheets. Turn on the printer, then turn on the computer. □...

  • Page 21: Accessing Advanced Features

    Macintosh Install: Software OS 8.6 to 9.1 (cont.) Accessing Advanced Features On-Line Manuals Requirements Mac OS 9.0.4 and higher • □ Acrobat Reader. Select File on the desktop menu. □ Click Print Desktop from the drop down menu. To Load the Manuals □...

  • Page 22: Adding The Printer

    Macintosh Install: Software OS X.1 and X.2 Install the Driver Adding the Printer Run the Print Center (Local HD → Applications → □ Note: Be sure to switch off antivirus software before Utilities → Print Center). installing a printer driver. □...
  • Page 24 OKI and OkiLAN are registered trademarks of Oki Electric Netscape and Netscape Navigator are U.S. trademarks of Industry Company, Ltd. Netscape Communications Corporation. PostScript is a trademark of Adobe Systems, Inc. which may Novell and NetWare are registered trademarks of Novell be registered in certain jurisdictions.
