1 Desktop Board Features

Table 1 describes the major features of Intel
Table 1.

Feature Summary

Form Factor
Processor
Main Memory
Chipset
Graphics
Audio
Peripheral Interfaces
®
Desktop Board D848PMB.
MicroATX 9.6-inches by 8.5-inches
Support for:
• Intel
® ®
Pentium 4 processor (1.60a, 1.80a, 2a, 2.2 GHz or higher) with
800/533/400 MHz front side bus (FSB) frequency in the mPGA478-pin
package
• Intel
®
Celeron processor (2 GHz or higher) with 400 MHz FSB frequency in
the mPGA478-pin package
• Two 184-pin, 2.5 V SDRAM Dual Inline Memory Module (DIMM) sockets
• Single channel 400/333/266 MHz DDR SDRAM interface
• Designed to support up to 2 GB of system memory
®
Intel 848P chipset consisting of:
• Intel
®
82848P Memory Controller Hub (MCH) with Accelerated Hub
Architecture (AHA) bus
• Intel
®
82801EB I/O Controller Hub (ICH5) with support for up to eight
Hi-Speed Universal Serial Bus 2.0 (USB 2.0) ports
• 4 Mbit Firmware Hub (FWH)
• Intel 848P chipset
• 1.5 V and 0.8 V only AGP connector
• Single AGP port via the connector
• AGP 3.0 including 1x/4x/8x AGP data transfers and 1x/4x/8x Fast Writes
• Intel 848P chipset (AC '97)
• Two channel audio
• RealTek ALC202A
• Up to eight USB 2.0 ports
— Four ports routed to the back panel
— Four ports routed to the internal USB headers
• Two IDE interfaces with Ultra DMA-33 and ATA-66/100 support
• Two Serial ATA (SATA) connectors
• One diskette drive interface
• One parallel port
• One serial port
• PS/2* keyboard and mouse ports
continued
