Desktop Board Components - Intel D848PMB Product Manual

Table 3.

Desktop Board Components

Label Description
A Front panel audio header
B CD-ROM audio connector (ATAPI-style)
C AGP connector
D Rear chassis fan header (fan speed control)
E 12 V processor core voltage connector
F Processor socket
G Processor fan header
H Intel 82848P (MCH)
I DIMM socket
J Main power connector
K Diskette drive connector
L Secondary IDE connector
M Primary IDE connector
N Front chassis fan connector (fan speed control)
O Chassis intrusion header
P Serial ATA connectors
Q BIOS configuration jumper
R Alternate power/sleep LED header
S Front panel header
T USB 2.0 header
U Intel 82801EB (ICH5)
V USB 2.0 header
W Battery
X PCI bus add-in card connectors
Y Speaker
Z Auxiliary line-in connector (ATAPI-style)
Related Links:
Go to the following links for the latest information about:
•
Intel Desktop Board D848PMB,
•
Processors, http://support.intel.com/support/motherboards/desktop
•
Audio software and utilities,
•
LAN software and drivers,
http://www.intel.com/design/motherbd
http://www.intel.com/design/motherbd
http://www.intel.com/design/motherbd
Desktop Board Features
13
