Installing the batteries

CAUTION: Use only AAA batteries. Remove the batteries if the remote control will not be used for
one month or longer. Do not attempt to recharge batteries not designed to be recharged. All
batteries should be replaced at the same time. Do not mix old and new batteries. Do not dispose of
batteries in a fire as they may explode.
EdgeStar Portable Air Conditioner

Remote Control Overview

Power Button
Fan Speed Button
Mode Button
Down Button
Button
Power
Fan Speed
Mode
(Down)
(Clock)
Timer
C/F
(Up)
1) Remove the cover on the back of the remote control.
2) Insert the batteries with the (+) and (-) ends pointing in the
correct direction.
3) Slide the cover back on.
LCD Display
C/F
Function
Powers the unit on or off.
Sets the fan speed. The
High, Medium or Low indicator will
appear depending on the mode you set.
Sets the mode. The
Cool, Dehumidify and
indicator will appear depending on the
mode you set.
Decreases the Temperature, Timer, or
Clock settings.
Used to set the remote control clock
Used to enable the timer.
Switches the temperature between
Celsius/Fahrenheit
Increases the Temperature Timer, or Clock
settings.
Clock Button
Timer Button
Celsius/Fahrenheit Button
Up Button
Automatic,
Automatic,
Fan
