Document Type: Service Manual
Version: V1.0 04132018
SERVICE MANUAL
Server Room Dual Hose Portable Air
Conditioner for Larger Rooms
MODEL:
AP14009COM-1
CAUTION: READ ALL SAFETY PRECAUTIONS IN THIS
MANUAL BEFORE SERVICING THE UNIT
EdgeStar, 8606 Wall St, Suite 1800, Austin, TX 78754
support.edgestar.com • service@edgestar.com • edgestar.com
*Warranty service should be performed by an authorized service representative only.
Advertisement
Table of Contents
Related Manuals for EdgeStar AP14009COM-1
Summary of Contents for EdgeStar AP14009COM-1
-
Page 1: Service Manual
Conditioner for Larger Rooms MODEL: AP14009COM-1 CAUTION: READ ALL SAFETY PRECAUTIONS IN THIS MANUAL BEFORE SERVICING THE UNIT EdgeStar, 8606 Wall St, Suite 1800, Austin, TX 78754 support.edgestar.com • service@edgestar.com • edgestar.com *Warranty service should be performed by an authorized service representative only. -
Page 2: Table Of Contents
CONTENTS CONTENTS ............................1 SAFETY PRECAUTIONS ........................1 ELECTRICAL SAFETY ........................2 GENERAL SAFETY ......................... 3 1 SPECIFICATIONS ........................... 4 2 EXPLODED VIEW AND PARTS LIST ....................5 3 WIRING DIAGRAM ........................7 4 REFRIGERANT SYSTEM DIAGRAM ....................7 5 MODES AND OPERATING CONDITIONS ..................8 5.1 TERMS AND DEFINITIONS ..................... -
Page 3: Electrical Safety
Electrical Safety Do not exceed the power outlet ratings. It is recommended that the unit be connected to its own circuit. A standard electrical supply that is properly grounded in accordance with the National Electrical Code and all state and local codes and ordinances is required. ... -
Page 4: General Safety
General Safety Always unplug an appliance from the power supply before attempting any service. Disconnect the power cord by grasping the plug, not the cord. Do not allow children or pets to play on or in the appliance. ... -
Page 5: Specifications
1 Specifications Description of product Portable Air Conditioner Model AP14009COM-1 Voltage / Frequency 115 V / 60 Hz Input Power 1250 W Current 10.8 A Cooling Capacity (SACC) 8500 BTU Cooling Capacity (ASHRAE) 14000 BTU Color Silver Coolant R-410A Timer 24 Hour ”... -
Page 6: Exploded View And Parts List
2 Exploded View and Parts List... - Page 7 PART NAME PART NAME BASE PLATE INDOOR TEMPERATURE SENSOR CASTOR BRACKET DRAIN PLUG POWER SUPPLY CORD DRAIN BUCKET COVER-B DRAIN BUCKET COVER-A AIR DEFLECTOR FLOAT BRACKET DISCHARGE GRILLE FLOAT TOP COVER PLATE FLOAT SWITCH BRACKET WATER FLINGER MOTOR PUSH BUTTONS COMPRESSOR LIGHT BOARD RUBBER FOOT...
-
Page 8: Wiring Diagram
3 Wiring Diagram 4 Refrigerant System Diagram... -
Page 9: Modes And Operating Conditions
5 Modes and Operating Conditions 5.1 Terms and Definitions TA: Ambient indoor temperature. TS: Set temperature. 5.2 Cooling Mode (Blue Light) The cooling temperature can be set from 64 to 90℉. The timer function works in cooling mode. The compressor will run when the difference between the set temperature and the actual ambient room temperature conforms to the chart below: Operation conditon (TA-Ts) ℉... -
Page 10: Dehumidify Mode (Yellow Light)
5.4 Dehumidify Mode (Yellow Light) In this mode, the air conditioner will operate as a dehumidifier. Because the conditioned space is closed or sealed, some degree of cooling will continue to occur. If the room temperature is below 77ºF, the fan will always run on low speed while in dehumidify mode. If you do not use the exhaust hose in Dehumidifying mode, you must manually drain the water from the unit. -
Page 11: Troubleshooting
6 Troubleshooting Problem Possible Cause Solution Wall plug is disconnected. Insert plug firmly into proper wall outlet. House fuse blown or circuit breaker tripped. Replace fuse with time delay type or reset circuit breaker. Press the RESET button on the power cord. If power cord is Power cord is tripped. -
Page 12: Base Plate
Base plate is cracked. Replace base plate. When unit is turned on or off the outer shell Normal sound. Outer shell is contracting or expanding and will “pops” or “clicks.” stop after a few minutes. When unit is turned on or off “boiling” or Normal sound. - Page 13 DATE REVISION NOTES 04/13/2018 INITIAL DOCUMENT EdgeStar, 8606 Wall St, Suite 1800, Austin, TX 78754 support.edgestar.com • service@edgestar.com • edgestar.com *Warranty service should be performed by an authorized service representative only.
