Product Specification/Installation Sheet
Description
The Liebert SiteLink-E is a product
platform that comes in three models:
SiteLink-12E, -4E and -2E. The models
differ only in the number of Emerson
family ports at the bottom of the module.
SiteLink-E supports Emerson interfaces
as a BACnet router that provides the
communications link between Liebert
units and other protocols and modules.
The SiteLink-E is designed to
communicate with Liebert equipment—
environmental units, UPSs and Power
Distribution Units—and route the
information over a BACnet, Modbus or
LONWorks™ network to a Building
Automation System (BAS) workstation.
Module Dimensions and Layout
Diagnostic
LED
indicators
Ethernet
port
BACnet
port
Rnet port
Local
access port
Xnet
remote
expansion
port
Module
Status
Error Codes
Chase = OK
0 = Download required
1 = Control Program Error
2 = RAM full
10/100 BaseT
3 = Comm setup error
4 = System error
Ethernet Port
8 = Formatting
3V Lithium Battery
Blinking Dot = 'Run'
CR-123A
100 LAN LINK
Format
®
BACnet
Over ARCNET156 KBaud
BT485
Net +
On Assigned
Net - ARCNET
Off Default
Shield Enhanced Access
on Rnet
Gnd
Rnet +
Local Access
Rnet
Rnet -
+12V
Xnet + Xnet
Xnet - Remote
Expansion
Gnd
SiteLink-12E
Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7
SiteLink-12E
11.3"
(287mm)
Power connector
ARCNET Transmit
ARCNET Receive
Archive Valid
Port S1 Transmit
Port S1 Receive
Battery low
10's 1's
Module
Address
+100 Enable Enable
0 Disable Disable
IP Addr Address MSTP PTP
on S1 on S1
485-4w
485-2w
Port 9-12
EIA-485
Net+, Net-, Net+Rx, Net-Rx
EIA-232 Tx, Rx, Gnd, Gnd
Port 8 Port 9 Port 10 Port 11
Port S1
1
24Vac, 24VA, 1A, 50-60 Hz
26Vdc, 10W, 0.4A
Ground
24ac/26dc
Power
On Off
External Gnd
Battery +3V
Ext. Batt.
Int. Batt.
BT485
Port S1
2 wire 4 wire EIA-232
Signal Ground
5.5"
n/c Rx - DCD
(139.7mm)
n/c Rx + DTR
Net- Tx - Rx
Net+ Tx + Tx
Port 12
0.23"
(5.8mm)
1"
(25.4mm)
7.5"
(190.5mm)
1"
(25.4mm)
