Decorative, Bowshield, Wall Mounted CFL
13 ⅝"
(346mm)
ADA Compliant
Complete Luminaire consists of Diffuser and Backplate Assembly. Order each separately.
Diffuser Ordering Information
Catalog No.
Pattern/Description/Color
40871
40865
40862
Backplate Assembly Ordering Information
Catalog No.
Finish
40828UEM
Satin Brass
40828UEM
Satin Brass
1
5
13 ⅛"
(333mm)
Rolled "Rain" pattern texture, Silk-screened White/Clear
Three Dimensional "Squares" White/Clear Silk-screened Pattern
"Ceramic White" Silk-screened and Sandblasted
Wattage
Ballast
18W
Electronic Universaal
18W
Voltage 120V or 277V
40829UEM
7
6
4
8
Recharge Time
24 Hours
Job Information
Type:
Job Name:
Cat. No.:
Notes:
Page 1 of 3
6 ⅞"
(175mm)
to outlet
box center
2
3
Charging Current
280 mA
