Lightolier 4SB324 Specification

Decorative, Pendalux Suspension, Basic Canopy
Complete Luminaire consists of Body and Suspension. Order each separately.
3 Cables to Single Stem Suspension, with Swivel, Basic Canopy.
Catalog No. Nominal Overall Length (A)*
4SB324PB 17 ⅞"
4SB324SB 17 ⅞"
4SB324SN 17 ⅞"
4SB324WH 17 ⅞"
4SB328PB 21 ⁄ "
11
16
4SB328SB 21 ⁄ "
11
16
4SB328SN 21 ⁄ "
11
16
4SB328WH 21 ⁄ "
11
16
4SB335PB 27 ⁄ "
5
16
4SB335SB 27 ⁄ "
5
16
4SB335SN 27 ⁄ "
5
16
4SB335WH 27 ⁄ "
5
16
4SB342PB 32 ⅝"
4SB342SB 32 ⅝"
4SB342SN 32 ⅝"
4SB342WH 32 ⅝"
*Add this length (A) to Body length (C) from Body Spec Sheet(s) to get Total Luminaire Nominal OAL.
4SB324
45º
3
6
Nominal Length (B)*
13 ⅜"
13 ⅜"
13 ⅜"
13 ⅜"
16 ¼"
16 ¼"
16 ¼"
16 ¼"
20 ½"
20 ½"
20 ½"
20 ½"
24 ½"
24 ½"
24 ½"
24 ½"
Job Information
Job Name:
Cat. No.:
Notes:
(28) (35) (42)
5
4
Body Diagram
Suspension (Center Stem) and Canopy Finish
Polished Brass
Satin Brass
Satin Nickel
White
Polished Brass
Satin Brass
Satin Nickel
White
Polished Brass
Satin Brass
Satin Nickel
White
Polished Brass
Satin Brass
Satin Nickel
White
Type:
Page 1 of 2
A
B
C
