5" RANDOM ORBITAL
SET uP AND OPERATINg INSTRucTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE ThIS MANuAL.
©
Copyright
2005 by Harbor Freight Tools
contained herein may be reproduced in any shape or form without the express written consent of Harbor
Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing improvements,
actual product may differ slightly from the product described herein.
For technical questions or replacement parts, please call 1-800-444-3353.
Manual Revised 10f
PALM SANDER
Model
®
. All rights reserved. No portion of this manual or any artwork
93431

Advertisement

Table of Contents
loading

Related Manuals for Chicago Electric 93431

Summary of Contents for Chicago Electric 93431

  • Page 1 5” RANDOM ORBITAL PALM SANDER Model 93431 SET uP AND OPERATINg INSTRucTIONS Visit our website at: http://www.harborfreight.com Read this material before using this product. Failure to do so can result in serious injury. SAVE ThIS MANuAL. © ® Copyright 2005 by Harbor Freight Tools .

  • Page 2: Important Safety Information

    NOTIcE is used to SAVE ThIS MANuAL address practices not Keep this manual for the safety warnings related to personal injury. and precautions, assembly, operating, cAuTION, without the inspection, maintenance and cleaning safety alert symbol, is procedures. Write the product’s serial number used to address practices not in the back of the manual near the assembly related to personal injury.
  • Page 3 increased risk of electric shock if your tools that have the switch on invites body is grounded. accidents. Do not expose power tools to rain or Remove any adjusting key or wrench wet conditions. Water entering a power before turning the power tool on. tool will increase the risk of electric A wrench or a key left attached to a shock.

  • Page 4: Safety Warnings Common For Sanding Operations

    the power tool before making any and specifications provided with adjustments, changing accessories, this power tool. Failure to follow all or storing power tools. Such instructions listed below may result in preventive safety measures reduce electric shock, fire and/or serious injury. the risk of starting the power tool Operations such as grinding, wire accidentally.
  • Page 5 wire brush for loose or cracked Position the cord clear of the spinning wires. If power tool or accessory accessory. If you lose control, the cord is dropped, inspect for damage or may be cut or snagged and your hand install an undamaged accessory.

  • Page 6: Kickback And Related Warnings

    the work by hand or against your body is to cause cancer, and birth defects or unstable and may lead to loss of control other reproductive harm. Wash hands and personal injury. after handling. (California Health & Safety Code § 25249.5, et seq.) This product is not a toy.

  • Page 7: Safety Warnings Specific For Sanding Operations

    start-up. The operator can control Anyone using vibrating tools regularly torque reactions or kickback forces, if or for an extended period should first proper precautions are taken. be examined by a doctor and then have regular medical check-ups to ensure Never place your hand near the medical problems are not being caused rotating accessory.

  • Page 8: Double Insulated Tools: Tools With Two Prong Plugs

    preceding illustration. (See Outlets for gROuNDINg 2-Prong Plug.) TO PREVENT Extension cords ELEcTRIc ShOcK AND DEATh FROM INcORREcT Grounded tools require a three wire gROuNDINg WIRE extension cord. Double Insulated cONNEcTION: tools can use either a two or three wire Check with a qualified electrician extension cord.
  • Page 9 REcOMMENDED MINIMuM WIRE gAugE FOR EXTENSION cORDS* (120/240 VOLT) EXTENSION cORD NAMEPLATE LENgTh AMPERES 25’ 50’ 75’ 100’ 150’ (at full load) 0 – 2.0 2.1 – 3.4 3.5 – 5.0 5.1 – 7.0 7.1 – 12.0 12.1 – 16.0 16.1 –...

  • Page 10: Specifications

    Attaching the Dust Bag SPEcIFIcATIONS Dust Electrical Input 120 V~ / 60 Hz / 2 A Bag (28) No Load Speed 12,000 OPM Orbit Diameter 3/32” 5” (127 mm) Max. Accessory 8 hole hook and loop Diameter 1x 80 grit sanding disc included E194601 uNPAcKINg Slide the Dust Bag onto the back of...

  • Page 11: General Operating Instructions

    Attaching Sandpaper to the Backing Pad approved eye and hearing protection, as well as heavy work gloves. Switch (15) Before beginning work, provide for sparks and debris that will fly off the work surface. general Operating Instructions Turn on the Sander using the Switch. Backing Run the Sander for a few seconds before Pad (23)

  • Page 12: Maintenance And Servicing

    MAINTENANcE AND WARNINg! If the supply cord of this power tool is damaged, it must be SERVIcINg replaced only by a qualified service technician. Procedures not specifically explained in this manual must be performed only by a qualified technician. TO PREVENT SERIOuS INjuRY FROM AccIDENTAL OPERATION:...

  • Page 13: Troubleshooting

    Troubleshooting Problem Possible causes Likely Solutions Tool will not start. Cord not connected. Check that cord is plugged in. No power at outlet. Check power at outlet. If outlet is unpowered, turn off tool and check circuit breaker. If breaker is tripped, make sure circuit is right capacity for tool and circuit has no other loads.

  • Page 14: Part Description Qty

    PLEASE READ ThE FOLLOWINg cAREFuLLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLy DIAgRAM IN THIS MANUAL AS A REFERENCE TOOL ONLy. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS qUALIFIED TO MAkE ANy REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS qUALIFIED TO REPLACE ANy PARTS OF THE PRODUCT.

  • Page 15: Assembly Diagram

    ASSEMBLY DIAgRAM (29) Sanding Disc (80 Grit) not shown SKU 93431 For technical questions, please call 1-800-444-3353. Page 15...

  • Page 16: Limited 90-Day Warranty

    LIMITED 90 DAY WARRANTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
