Installation

Water Connection

GB
Connecting the cold water inlet hose
! Remember: please use the new hose supplied,
fitted to the machine. Old hoses may cause leaks due
to worn out washers or may be split due to water
pressure.
! Before making connections to the cold water supply,
allow the water to run freely from the supply tap until it
is perfectly clear.
WATER
OFF
SUPPLY
4
ON
3
/ " Sealing
4
Cap (not
supplied)
1. Screw the cold water fill hose (blue connector) onto
the cold water supply until tight.
2. Fit a 3 / " sealing cap to the hot water supply, to
4
prevent unused supply leaking.
3. Turn on the cold water supply and check for leaks,
tighten if necessary.
4. Leave the unused hot water supply turned off.
6
HOT WATER SUPPLY
(if present)
COLD WATER
SUPPLY
OFF
3
WATER
ON
SUPPLY
1
2
Cold water fill
hose (Blue
Connector)
! We recommend fitting a 3/4"
sealing cap to the hot water
supply tap (if present), to ensure
there are no leaks. Sealing caps
can be purchased from Hotpoint
Service on 08709 077 077 or all
good DIY and Plumbing outlets.

Technical Details

Dimensions 59.5cm wide
85cm high
60cm deep
Electric voltage: 220/240 Volts 50Hz
connections maximum absorbed power:
1700W-2100W
Water maximum pressure 1 MPa (10 bar)
connections minimum pressure 0.05 MPa (0.5 bar)
Benefits of cold fill
Modern detergents are designed to give the best
cleaning results at low temperatures. Biological
detergents contain enzymes which are active
between 30˚C and 53˚C, giving greater results at
lower temperatures.
Cold water relaxes fabrics, whilst hot water can
seal in stains.
Improved stain removal with cold water.
The most commonly used programme at present is
40˚C, which will take on cold water even if hot and
cold were available.
You can heat the water required to finish the wash
cycle, which makes it more economical than taking
water heated in a tank by an immersion heater or
gas boiler.
Hints and tips
! Make sure there are no kinks or bends in the hose.
! The water pressure at the supply tap must be within
the values indicated in the Technical details table (see
above).
! If the water inlet hose is not long enough, you can
purchase an extended hose from Hotpoint Service on
08709 077 077.
! Always use a new inlet hose.
! Check the water inlet hose at least once a year,
replace if cracked as worn hoses could split under
water pressure.
