Care and maintenance

Cleaning
GB
! Do not clean any part of the machine with abrasive
cleaners, scouring agents, acids, any bleach or metal
polish as they may cause damage.
Use a damp cloth or silicon polish to clean the
exterior surfaces of the appliance.
Clean the internal surface of the door bowl regularly
with a soft cloth. A build up of soap powder and
water hardness residue may result in water leaking
from the door.
Always leave the appliance door ajar to prevent
unpleasant odours from forming.
Cleaning the dispenser drawer and compartments
It is advisable to clean the dispenser drawer regularly.
! Do not try to clean any part of the dispenser drawer
while the machine is running.
! We recommend a maintenance wash 2 or 3 times a
year, to avoid a build up of greasy deposits and water
hardness residue. Run the 95˚ White Cotton programme,
with the normal amount of detergent but no laundry.
(Washer Dryer only) Where the drying only option is
regularly used, do this on a monthly basis.
Moulded plug
10
1. Pull out the drawer until it
reaches its stop.
2. Press the drawer release
button to remove the dispenser
drawer (see pic).
3. Clean and dry the dispenser
drawer, syphons, grate and
fabric conditioner exit channel
(A), ensuring any build up of
detergent and fabric conditioner is
fully removed. Failure to do so
may lead to the machine leaking
A
from the dispenser drawer.
Also regularly clean the
outlet pipe area (B).
4. Relocate the dispenser drawer
B
and push it firmly back into place.
! The plug must not be used without
the fuse cover in place.
If a replacement fuse holder/cover
is required, it must be of the
same colour coding or wording as
shown on the base of the plug.
Replacements are available from
authorised dealers.

Changing the plug

The wires in the power cord are coloured in accordance
with the following:
Green and Yellow
(Earth) wire to terminal
marked 'E', symbol ,
or coloured green and
yellow.
Blue (Neutral) wire to
terminal marked 'N' or
coloured black.
Cord clamp
! If the plug being replaced is a non-rewirable type,
then the cut-off plug must be disposed of safely.
DO NOT leave it where it can be inserted into a socket
and create a shock hazard.
! The power supply cord should be checked periodically
and replaced by a cord specially prepared for this
machine and fitted only by authorised technicians (see
Service). Replacement power cords can be purchased,
at an extra cost from our Genuine Parts and
Accessories department or authorised dealers.
! The manufacturer denies any responsibility should
any of these rules not be followed.
! If in doubt about any of the above consult a
qualified electrician.

Cleaning the pump

( Varies by Model*)
This appliance is fitted with a self-cleaning pump that
does not require any maintenance.
Sometimes, small items (such as coins or buttons) may
fall into the pre-chamber that protects the pump.
! Make sure the wash cycle has ended and unplug the
appliance.
To access the chamber:
1. Using a screwdriver, remove
the kickstrip on the lower front of
the appliance (see figure).
2. Unscrew the pump filter by
rotating it anti-clockwise, until it
can be removed (see figure).
A little water may leak from the
pump: this is perfectly normal.
3. Clean the interior thoroughly, removing any visible debris.
4. Refit by screwing the filter into place until it reaches
its 'stop' position.
5. Refit the kickstrip, making sure that the hooks are
securely in place before you push it onto the appliance.
* NOT ALL MODELS HAVE THIS FEATURE.
13A ASTA approved
fuse to BS1362.
Brown (Live) wire to
terminal marked 'L' or
coloured red.
