DEFINITY AUDIX System Release 4.0
System Description Pocket Reference 585-300-214
Customer Responsibilities

Cable Connections

Table B-2. Air Purity Requirements
Contaminant
Total particulate matter, including the following:
Dust
Lint
Carbon particles
Paper fiber
Metal fragments
Nitrate in particulate matter
Corrosive gases
Total hydrocarbons equivalent to methane
Sulphur dioxide
Oxides of nitrogen
Total oxidants equivalent to ozone
Hydrogen sulfide
Cable Connections
The customer is responsible for providing several connections from the
customer's facilities to the DEFINITY AUDIX system. These connections
divide maintenance responsibilities between Lucent Technologies and
the customer:
All customers must provide a Cmentral Office (CO) line or a Direct
Inward Dialing (DID) line to connect the modem to an external
telephone network for remote maintenance.
All customers must provide a power source for the external
1
modem.
Customers using I
10BaseT to connect the DEFINITY AUDIX system to the
customer's local area network (LAN).
Figure B-1 shows the connections customers must provide for the
external modem.
1. Customers outside the U.S. must provide an external modem.
Message Manager must provide a
NTUITY
Average concentration
185.00 microgram/m
12.00 microgram/m
10.00 ppm
0.20 ppm
0.30 ppm
0.05 ppm
0.10 ppm
1
May 1999
3
3
Issue 1
B-3
