XDMA5280 OPERATION
General Operation
Audio Press AUDIO momentarily to select between Bass, Treble,
Balance, Fader, Equalizer and Source Volume Level.
BASS TREBLE BALANCE FADER EQUALIZER SOURCE LEVEL
Bass
Press AUDIO until BASS appears then rotate volume knob
left/right to adjust ( -6 minimum / +6 maximum).
Treble Press AUDIO until TREBLE appears then rotate volume knob
left/right to adjust ( -6 minimum / +6 maximum).
Balance Press AUDIO until BAL appears then rotate volume knob
left/right to adjust (BAL L12 - BAL R12).
BAL EVEN represents equal balance
Fader Press AUDIO until FADER appears then rotate volume knob
left/right to adjust (FADER F12 - FADER R12).
FAD EVEN represents equal fader
Equalizer Press AUDIO until EQ appears then turn the volume knob
to cycle through the following equalization curves: FLAT
(default), POP, JAZZ, CLASSIC, BEAT, ROCK and USER.
Any manual adjustment to the Bass or Treble settings are
automatically saved as USER.
Source Volume Level The source volume level control allows a gain adjustment
for each audio source: AM, FM, CD, AUX, operation of iPod
and USB. Set the source volume level for each mode,
depending on the relative volume of each audio source.
To set the source volume level, press AUDIO until SRC
LEVEL appears. After one second, the current mode will
appear on the display. Turn the volume knob to adjust
the audio level of the current source (-6 minimum/+6
maximum).
Note: Only the current mode will be available for
adjustment. To adjust another mode of operation, press
SOURCE until the desired mode is selected, then set the
source volume level for that mode.
