PRODUCT NO.
BASE MODEL NO.
FRS26ZNHQ2
FRS26ZNH
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
bisque
Publication No.
5995330692
991206
-EN/SERVICE /ECL
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZNH
©1999 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26ZNH

Summary of Contents for Frigidaire FRS26ZNH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZNHQ2 FRS26ZNH R134a bisque MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218954000 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR 101 Masters Blvd.

  • Page 2: Freezer Door

    Publication No. FRS26ZNHQ2 5995330692 FREEZER DOOR 12/99...
  • Page 3 FRS26ZNHQ2 Publication No. 5995330692 FREEZER DOOR POS. NO PART NO DESCRIPTION 215734313 Gasket-frzr door,white ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 218807028 Rack-door,w/end caps 215474052 Rack-door 218510401 Panel-inner door,frzr 5303918152 Panel-frzr door,bisque ,w/foam insulatn 5303289522 Door Stop 218762706 Handle-door,bisque...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZNHQ2 5995330692 REFRIGERATOR DOOR P58R0078 12/99...
  • Page 5 FRS26ZNHQ2 Publication No. 5995330692 REFRIGERATOR DOOR POS. NO PART NO DESCRIPTION 215734314 Gasket-refr door,white ,magnetic 215403201 Panel-inner door,refr 5303304563 Door-dairy 5303289522 Door Stop 5303918151 Panel-refr door,bisque ,w/foam insulatn 218762706 Handle-door,bisque 218886801 Screw-8-32 X 1/2 #10 Truss ca,8 32 x 1/2 #10 218578600 Screw-door stop mtg,phl truss hd ,10-16 x 3/4 5303289320...
  • Page 6 Publication No. FRS26ZNHQ2 5995330692 CABINET 12/99...
  • Page 7 FRS26ZNHQ2 Publication No. 5995330692 CABINET POS. NO PART NO DESCRIPTION 215637602 Cover-air duct 5303209814 Nut,"U" type ,8-15(A) ,fan mtr mtg 215637401 Cover-evap coil,lower 10A* 5308009617 Washer,ext tooth lock ,#10 ,grounding 5303208309 Plug-hole,factory test 215230400 Plug-harness hole 5303289043 Support-air duct cvr,2.55" long 5303289044 Support-air duct cvr,1.83"...
  • Page 8 Publication No. FRS26ZNHQ2 5995330692 SHELVES 12/99...
  • Page 9 FRS26ZNHQ2 Publication No. 5995330692 SHELVES POS. NO PART NO DESCRIPTION 5303298147 Trim-basket 218298003 Shelf-freezer,sliding ,wire 218159700 Spacer-shelf 5304405879 Shelf-freezer,fixed wire 218815501 Shelf-pizza,24B 215029009 Shelf-"Spill-Safe",cantilever ,sliding 215124343 Cover-storage pan 5303301393 Control-humidity 5304412757 Trim-storage pan cvr,upper ,w/humidity hole 218015302 Trim-storage pan cvr,snap-on ,front 218015402 Trim-storage pan cvr,snap-on ,rear 5303289500...
  • Page 10 Publication No. FRS26ZNHQ2 5995330692 CONTROLS 12/99...
  • Page 11 FRS26ZNHQ2 Publication No. 5995330692 CONTROLS POS. NO PART NO DESCRIPTION 215028605 Knob-damper control 5308000010 Fan Blade,red 5308000124 Ring-fan orifice 5300157666 Bushing-motor mtg,(2) 5304414684 Bracket-motor mtg,front 215809600 Diffuser-air 13 # 215426200 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303205119 Bracket-motor mtg,rear 5303001179 Light Bulb/Lamp,40 W 16 #...
  • Page 12 Publication No. FRS26ZNHQ2 5995330692 SYSTEM 12/99...
  • Page 13 FRS26ZNHQ2 Publication No. 5995330692 SYSTEM POS. NO PART NO DESCRIPTION 218787900 Condenser 5303208866 Spacer-cond tube,black 5303289026 Spacer-tube 5304406721 Spacer-cond tube,round ,5/8 OD x .81"lg 5303289029 Clip-cond mtg,(4) 218679603 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 218959901 Wiring Harness,main 215005200 Wiring Harness,refr controls 218815101 Wiring Harness,frzr controls 218960201...
  • Page 14 Publication No. FRS26ZNHQ2 5995330692 DISPENSER 12/99...
  • Page 15 FRS26ZNHQ2 Publication No. 5995330692 DISPENSER POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet,93" ,plastic ,cut-to-size 218832301 Tube-water inlet,inlet valve ,to filter 218859901 Tube-water inlet,inlet valve ,to filter 218949201 Tube-water inlet,formed ,plastic ,dispenser 218505304 Deflector-ice disp,bisque 215484300 Heater-door housing 218852404 Housing-dispenser,bisque 218284800 Switch-actuator,micro 218874901...

  • Page 16: Ice Container

    Publication No. FRS26ZNHQ2 5995330692 ICE CONTAINER 12/99...
  • Page 17 FRS26ZNHQ2 Publication No. 5995330692 ICE CONTAINER POS. NO PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 16 # 5303289050 Socket-light/lamp 5304404345 Drive Blade 18 # 5304404330 Motor-auger 5304404335...

  • Page 18: Ice Maker

    Publication No. FRS26ZNHQ2 5995330692 ICE MAKER 12/99...
  • Page 19 FRS26ZNHQ2 Publication No. 5995330692 ICE MAKER POS. NO PART NO DESCRIPTION 5318582501 Tube-water inlet,93" ,plastic ,cut-to-size 218832301 Tube-water inlet,inlet valve ,to filter 218859901 Tube-water inlet,inlet valve ,to filter 218949201 Tube-water inlet,formed ,plastic ,dispenser 3206348 Spring,shut-off arm 3206299 Plate-I.D. 3206301 Gear 3206303 Plate-mounting 3206305...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZNHQ2 5995330692 WIRING SCHEMATIC 12/99...

  • Page 21: Wiring Diagram

    FRS26ZNHQ2 Publication No. 5995330692 WIRING DIAGRAM # = Fast-moving Parts 12/99 * = Non-Illustrated Parts...
