Frigidaire FRS26ZNH Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRS26ZNH
  6. Factory parts catalog
Frigidaire FRS26ZNH Factory Parts Catalog

Frigidaire FRS26ZNH Factory Parts Catalog

Side by side
Hide thumbs Also See for FRS26ZNH:

Advertisement

Table of Contents

PRODUCT NO.
BASE MODEL NO.
FRS26ZNHB4
FRS26ZNH
FRS26ZNHD4
FRS26ZNH
FRS26ZNHQ4
FRS26ZNH
FRS26ZNHW4
FRS26ZNH
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909401
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
bisque
R134a
white
Publication No.
5995343042
000905
-EN/SERVICE /DJH
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZNH
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26ZNH

Summary of Contents for Frigidaire FRS26ZNH

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. FRS26ZNHB4 FRS26ZNH FRS26ZNHD4 FRS26ZNH FRS26ZNHQ4 FRS26ZNH FRS26ZNHW4 FRS26ZNH MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218954000 SERVICE DATA SHEET - # 218909401 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG...

  • Page 2: Freezer Door

    Publication No. FRS26ZNH 5995343042 FREEZER DOOR 9/00...
  • Page 3 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH FREEZER DOOR PART NO DESCRIPTION 215734323 A - - - Gasket-frzr door,black ,magnetic...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZNH 5995343042 REFRIGERATOR DOOR 9/00...
  • Page 5 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH REFRIGERATOR DOOR PART NO DESCRIPTION 215734324 A - - - Gasket-refr door,black ,magnetic...
  • Page 6 Publication No. FRS26ZNH 5995343042 CABINET 9/00...
  • Page 7 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 10A* 30A* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH CABINET PART NO DESCRIPTION 215637602 A B C D Cover-air duct...
  • Page 8 Publication No. FRS26ZNH 5995343042 CABINET 9/00...
  • Page 9 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH CABINET PART NO DESCRIPTION 218249802 A B C D Seal-coil cover,(2) 218154003...
  • Page 10 Publication No. FRS26ZNH 5995343042 SHELVES 9/00...
  • Page 11 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH SHELVES PART NO DESCRIPTION 5303298147 A B C D Trim-basket 218298003...
  • Page 12 Publication No. FRS26ZNH 5995343042 CONTROLS 9/00...
  • Page 13 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 13 # 16 # 17A* 21 # 23 # 114# 141* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH CONTROLS PART NO...
  • Page 14 Publication No. FRS26ZNH 5995343042 SYSTEM 9/00...
  • Page 15 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 13 # 14 # 15 # 21 # 29 # 30 # 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts...
  • Page 16 Publication No. FRS26ZNH 5995343042 DISPENSER 9/00...
  • Page 17 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 12A* 17A* 33 # 35 # 38 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH DISPENSER PART NO...

  • Page 18: Ice Container

    Publication No. FRS26ZNH 5995343042 ICE CONTAINER 9/00...
  • Page 19 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 16 # 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH ICE CONTAINER PART NO DESCRIPTION 5304404344 A B C D...

  • Page 20: Ice Maker

    Publication No. FRS26ZNH 5995343042 ICE MAKER 9/00...
  • Page 21 A = FRS26ZNH (FRS26ZNHB4) B = FRS26ZNH (FRS26ZNHD4) C = FRS26ZNH (FRS26ZNHQ4) D = FRS26ZNH (FRS26ZNHW4) POS. NO 11 # 12 # 13 # 15 # 17 # 141* # = Fast-moving Parts * = Non-Illustrated Parts FRS26ZNH ICE MAKER...

  • Page 22: Wiring Schematic

    Publication No. FRS26ZNH 5995343042 WIRING SCHEMATIC 9/00...

  • Page 23: Wiring Diagram

    FRS26ZNH Publication No. 5995343042 WIRING DIAGRAM # = Fast-moving Parts 9/00 * = Non-Illustrated Parts...
