  • Page 1 FRS26ZPHB4 FRS26ZPH R134a black FRS26ZPHD4 FRS26ZPH R134a almond FRS26ZPHQ4 FRS26ZPH R134a bisque FRS26ZPHW4 FRS26ZPH R134a white North America P.O. BOX 212378, Augusta, GA 30917 Publication No. 5995348215 010109 -EN/SERVICE/KHB ©2001 White Consolidated Industries, Inc. All rights reserved...

  • Page 2: Freezer Door

    Publication No. FRS26ZPH 5995348215 FREEZER DOOR 01/01...
  • Page 3 FRS26ZPH Publication No. 5995348215 FREEZER DOOR A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 215734323 A - - - Gasket-frzr door,black ,magnetic 215734313 - B C D Gasket-frzr door,white ,magnetic 5303288950 A B C D Support-door rack,RH/LH 5303323484 A B C D...

  • Page 4: Refrigerator Door

    Publication No. FRS26ZPH 5995348215 REFRIGERATOR DOOR 01/01...
  • Page 5 FRS26ZPH Publication No. 5995348215 REFRIGERATOR DOOR A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 215734324 A - - - Gasket-refr door, black, magnetic 215734314 - B C D Gasket-refr door, white, magnetic 215403201 A B C D Panel-inner door, refr...
  • Page 6 Publication No. FRS26ZPH 5995348215 CABINET 01/01...
  • Page 7 FRS26ZPH Publication No. 5995348215 CABINET A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 215637602 A B C D Cover-air duct 5303209814 A B C D Nut,"U" type ,8-15A ,fan mtr mtg 215637402 A B C D Cover-evap coil,lower 5303208309...
  • Page 8 Publication No. FRS26ZPH 5995348215 SHELVES 01/01...
  • Page 9 FRS26ZPH Publication No. 5995348215 SHELVES A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 5303298147 A B C D Trim-basket 218298003 A B C D Shelf-freezer,sliding ,wire 218159700 A B C D Spacer-shelf 5304405879 A B C D Shelf-freezer,fixed wire...
  • Page 10 Publication No. FRS26ZPH 5995348215 CONTROLS 01/01...
  • Page 11 FRS26ZPH Publication No. 5995348215 CONTROLS A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 215028605 A B C D Knob-damper control 5308000010 A B C D Fan Blade,red ,evaporator fan 5308000124 A B C D Ring-fan orifice 5300157666 A B C D...
  • Page 12 Publication No. FRS26ZPH 5995348215 SYSTEM 01/01...
  • Page 13 FRS26ZPH Publication No. 5995348215 SYSTEM A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 218787900 A B C D Condenser 5303208866 A B C D Spacer-cond tube,black 5303289026 A B C D Spacer-tube 5303289029 A B C D Clip-cond mtg,(4)
  • Page 14 Publication No. FRS26ZPH 5995348215 DISPENSER 01/01...
  • Page 15 FRS26ZPH Publication No. 5995348215 DISPENSER A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 218976908 A B C D Tube-water inlet, filter to filter valve 218949201 A B C D Tube-water inlet, formed, plastic, dispenser 5308010366 A B C D Tube-water inlet, 0.25 OD x 93"...

  • Page 16: Ice Container

    Publication No. FRS26ZPH 5995348215 ICE CONTAINER 01/01...
  • Page 17 FRS26ZPH Publication No. 5995348215 ICE CONTAINER A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 5304404344 A B C D Auger-ice 5304404343 A B C D Cam-drive 218815300 A B C D Container-ice,bucket only 5304404346 A B C D Drum-ice disp...

  • Page 18: Ice Maker

    Publication No. FRS26ZPH 5995348215 ICE MAKER 01/01...
  • Page 19 FRS26ZPH Publication No. 5995348215 ICE MAKER A = FRS26ZPH (FRS26ZPHB4) B = FRS26ZPH (FRS26ZPHD4) C = FRS26ZPH (FRS26ZPHQ4) D = FRS26ZPH (FRS26ZPHW4) 218976908 A B C D Tube-water inlet, filter to filter valve 218949201 A B C D Tube-water inlet, formed, plastic, dispenser 5308010366 A B C D Tube-water inlet,0.25 OD x 93"...

  • Page 20: Wiring Schematic

    Publication No. FRS26ZPH 5995348215 WIRING SCHEMATIC 01/01...

  • Page 21: Wiring Diagram

    FRS26ZPH Publication No. 5995348215 WIRING DIAGRAM # = Fast-moving Parts 01/01 * = Non-Illustrated Parts...
