Fetal damage in pregnant women the spa. This does not apply to lights built in to the • Physical inability to exit the spa spa as factory options from Cal Spas™. • Unconsciousness WARNING -- RISK OF INJURY WARNING: The use of alcohol, drugs, or medi- The spa water should never exceed 104˚F (40˚C).
Preparing for Your New Inground Spa Most cities and counties require permits for exterior construction and electrical circuits. In addition, some communities have codes requiring residential barriers such as fencing and/or self-closing gates on property to prevent unsupervised access to the property by children. Your dealer can provide information on which permits may be required and how to obtain them prior to the delivery of your Cal Spa.
Planning the Best Place for the Outdoor Equipment Pack The Designer Spa series requires an external equip- owner’s manual for important location and safety ment pack. When locating the outdoor equipment information.) pack, you will want to consider the following: •...
Electrical Requirements – US and Canada All 240V spas must be permanently connected (hard Wire runs over 85 feet must increase wire gauge to wired) to the power supply. These instructions de- the next lower number. For example: A normal 50 scribe the only acceptable electrical wiring procedure.
Electrical Installation -- Europe All 230V spas must be permanently connected (hard Wire runs over 85 feet must increase wire gauge to wired) to the power supply. These instructions de- the next lower number. For example: A normal 50 scribe the only acceptable electrical wiring procedure. amp RCD with four #8 AWG copper wires run over Spas wired in any other way will void your warranty 85 feet would require you to go to four #6 AWG cop-...
Equipment Pack Plumbing Connections Equipment Pack Specifications All Inground spas except IGJ-407: Equipment pack weight = 250 lbs. IGJ-407: Equipment pack weight = 300 lbs. One 2.5 HP heat pump One 4 HP swim pump Note: Equipment pack cannot exceed 15 feet from spa.
Page 19
Gate/Slice Valves The plumbing on the spa shell is labeled by the factory in the following manner: The use of gate valves is recommended on all plumb- ing lines (both suction and return lines). These valves Pump 1 Suction: 2” line that connects the spa filter are used to contain the spa’s water in either the equip- and bottom drain assembly to the front of pump 1.
Electrical and Electronic Connection Remote Equipment Topside Control Connect the extension loom to the control panel Panel location on the circuit board located inside the control box. You will also need to connect both The next few steps to complete the installation should the temperature and high limit sensors to the cir- be performed along with installation of the tempera- cuit board prior to testing.
Page 21
Inground Spa Light Installation In- Feed the light cord through the rigid conduit to the junction box, leaving at least 4 feet of cord at structions the end of the light fixture. This slack in the light On spas ordered with inground lights, the factory cord will allow servicing without draining the spa installs the light niche for you.
Page 22
Inground Spas LTR20111002, Rev. A www.calspas.com...
Pouring the Deck just under it. This is important, as concrete should be It is recommended that all electrical hook ups and all packed under and over the flange of the spa, as the plumbing be completed before pouring the concrete. deck is poured.
9800 Electronic Control Operation Initial Start-up When first powered up, your spa will perform a self-diagnostic check and then automatically go into priming mode. The topside will display PR to indicate this. Priming mode will be active for less than five minutes. When the spa has finished priming, the heater will be activated and the water temperature will be maintained in stan- dard mode.
on, the equipment will automatically turn off after 15 • The first filter cycle is automatically activated at minutes. 8:00 AM and operates the pump until 10:00 AM. The “FILTER 1” indicator icon will light when filter Light 1 is running. Press the “LIGHT”...
Periodic Reminder Messages Press the “Mode” button to reset a displayed reminder. Message Frequency Action Required Every 7 days Test and adjust chemical levels per manufacturer’s instructions. Every 7 days Test and adjust chemical levels per manufacturer’s instructions. Every 30 days Remove, clean, and reinstall filter per manufacturer’s instructions.
Diagnostic Messages Message Meaning Action Required No message 1) Spa temperature is unknown. 1) After pump has been running for 2 minutes tempera- on display ture will be displayed. 2) Spa is in Economy or Sleep 2) In Economy or Sleep mode, the pump may be off for mode.
Page 28
Message Meaning Action Required Overheat protection (spa is shut- DO NOT ENTER THE WATER! down). One sensor has detected Remove the spa cover and allow spa to cool below 118˚F (48˚C) at the heater. 107˚F (42˚C). Press any button on the topside display to reset spa.
Adjustable Jets Diverter Knobs Almost all of the jets in your spa are adjustable. Diverter knobs are 1” and 2” knobs located around Rotating the face of an adjustable jet to the left the top of your spa. They allow you to divert water (counter-clockwise) will decrease the amount of through jets from one side of the spa to the other, or water flow through the jet.
Clear Water Plan Contents of this section: This section is intended for new spa owners with Testing and Adjusting Spa Water no experience with water chemistry. Everyone’s ex- perience with maintaining water quality is different, Sanitation but there are some general concepts you need to Filtration know.
Low TA can be corrected by adding Cal Spas “pH-Alkalinity Up”. If the CH is too low, add Cal Spas “Liquid Hardness Increaser”. If the TA is too high, the pH level will tend to be too high and may be difficult to bring down.
Do not use a floater. When you begin with fresh water, add 2 ounces of Cal Spas Go Brom. Open all of the jets and run the spa at high speed. This is your base bromine level as the tablets will take a while to dissolve.
Do not use chlorinating shock, which will damage your spa’s jets and pump seals. The only shock you should use is Cal Spas Oxidizer Shock. It is an easy way to maintain either chlorine or bromine chemical plans. For best results use the directions below.
Remove the filter by turning it counterclockwise, unscrewing the bottom threads, then pulling it up and out. Place the dirty filter into a bucket of water deep enough to cover the filter. Add 8 oz of Cal Spas “Liquid Filter Cleaner” to the bucket of water.
Adjust pH if necessary (between 7.2 to 7.8). cals. Damage to the spa or spa’s components from Pour in 16 oz of Cal Spas “Metal Protector” in the improper chemicals or chemical usage is not covered center of the spa.
We recommend that your spa water be changed every 4 to 6 months. You may find the need to change your spa water more frequently with heavy use. When empty, your spa should be cleaned with a non-abrasive cleaner, such as Cal Spas™ All Surface Cleaner, and then rinsed thoroughly. Inground Spas LTR20111002, Rev.
Cleaning and Maintenance Removing and Reseating the Pillows You can remove the pillows for cleaning and maintenance quickly and easily. This method works for all types of pillows. Grab the lower edge of the pillow with both hands firmly and pull up. As you do this, the pillow inserts will pop out of the holes.
Draining Your Spa Your spa should be drained every four to six months, and refilled with fresh tap water. The following is the recommended method for draining your spa. Turn off the power at the breaker. Remove all filters. Hook up the female end of a garden hose to the drain fitting (if equipped). Place the other end of the garden hose where you would like the water to drain to.
Due to the constant punishment your spa cover and pillows receive, you should protect them by applying Vinyl and Leather Cleaner as part of your monthly maintenance plan. Cal Spas™ Vinyl and Leather Cleaner is specifically designed to protect spa covers and pillows from chemical and ultraviolet light damage. It ac- complishes this without leaving an oily residue behind that is normally associated with common automotive vinyl protectants.
Page 41
Wipe clean with a soft cloth. wax) Repeat on heavily calcified areas. Cal Spas™ Fast Sheen is an essential part of main- Wipe spa thoroughly with a wet taining your spa’s finish. Through normal use, the sponge, rinsing often in a bucket spa’s finish can accumulate dirt, oil, and calcium,...
ACU02200300 ACU02200301 ACU02200305 ACU02200306 ACU02200302 ACU02200303 ACU02200304 93 x 200 Warranty Cal Spas Designer Inground Spas do not come with a warranty. If you have any questions, contact Cal Spas customer service at 1-800-CAL-SPAS. Inground Spas LTR20111002, Rev. A www.calspas.com...
LMS Customer Service Department 1462 East Ninth Street Pomona, CA 91766 Toll Free: 1-800-CAL-SPAS Fax: 1-909-629-3890 www.calspas.com LTR20111002, Rev. A 1/24/11...
