Power Supply and
Protection Ground
LEDs
Table 1 Router 5000 Family Console Port Specifications
Attribute
Command line interface
Table 2 lists the attributes of the Router 5000 Family AUX port.
Table 2 Router 5000 Family AUX Port Specifications
Attribute
Connector type
Interface standard
Baud rate
Services supported
Backup
Protocols supported
SLIP
Table 3 lists the attributes of the Router 5000 Family Ethernet port.
Table 3 Router 5000 Family Ethernet Port Specifications
Attribute
Connector type
Interface type
Frame format supported
Ethernet _ SNAP
IEEE 802.3
10/100BASE-T Mbps autosensing
Network protocol supported
Table 4 lists specifications for the Router 5000 Family power supply and protection
ground.
Table 4 Router 5000 Family Power Supply and Protection Ground
Item
Power supply input
Protection ground
Table below describes the LEDs on the Router 5012
POWER
SYSTEM
Router 5000 Family Hardware
Description
Description
RJ-45
Asynchronous EIA/TIA-232
300 to 115.2 kbps
Modem dial-up
Operating as the console port when the CON
fails
PPP
MP
Description
RJ-45
MDI
Ethernet _ II
IEEE 802.2
Operating mode
Full duplex/half duplex
IP, Novell IPX
Description
Rated Voltage: 100-240V, a.c. 50/60Hz
Max. voltage 90-264V a.c.50/60Hz
Connecting to ground through ground wire.
ON — The module (MIM or SIC) is operating
normally.
OFF — No module is installed in the current
slot or the MIM is not operating normally.
Flashing-unit is operating normally
OFF-power is Off
5
