ESP1010

5. Exterior Features

1. Rack

- Front Part -
1) MIC. +48V
WARNING: To use the +48V Phantom power supply, you need to connect an
optional external power supply to the ESP1010 rack.
WARNING: To prevent loud clicking via your monitor speakers, do not connect
your microphone while Phantom power is turned on.
WARNING: To prevent loud clicking via your monitor speakers, please turn off
the "MIX OUT" button on ESP1010 software panel when you connect an
external device to the inputs, especially a microphone.
2) Analog Inputs (1~4) - line input ports for Input 1~4.
①(In1~2) –XLR MIC input 1 ~2 ports
②(+48V) – Phantom power switch
- 5 - 5
