2. Installing ESP1010 PCI card
1) Look for an empty PCI slot. If you do not know which one is a PCI slot,
please read the following:
2) The PCI slot is the most common and is used for a wide range of
devices from the soundcard to the modem. Usually, the PCI slot is the
white-colored slot. It should not be too hard to find the PCI slot for
ESP1010.
3) If there is a guide blocking the empty slot, please remove the guide
using a proper screwdriver.
4) Put the ESP1010 PCI card into the slot and make sure it is placed in the
slot correctly. Insert the card into the slot and then tighten the screw.
Close the case.
5) Connect D-SUB cable from PCI card to Rack box.
6) Connect the I/O cable's connector to the ESP1010 PCI card.
