Front Panel (cont.)

9. Mic Input

Plug in a balanced mic into this XLR input for vocal or for your instrument. The
Loudbox Mini makes an excellent mini-PA or vocal monitor. You may also
connect an outboard preamp with balanced XLR out to this input.
10. Gain
Use the Gain knob to set the signal level for the Microphone input.
11. Low
Boost here to add weight to the microphone's sound. In general, boost bass at
low volumes and fl atten it out (or cut) at higher levels. With the dial set at
12 o'clock, the control is effectively out of the circuit.
12. High
Boost highs to add "air" to the sound of the microphone. With the knob set at
12 o'clock, the control is effectively out of the circuit.
13. Reverb
Controls the amount of digital reverb in the Microphone channel.

14. Master Volume

Set the overall level of the Loudbox Mini with the Master Volume. In general
put the Master Volume as high as possible (2 o'clock to 5 o'clock) to achieve the
cleanest sound.
15. Power
Lights up when the amplifi er power is on. The Power switch is located behind
the amp above the AC power cord terminal.
9 10 11 12 13
7
14 15
