- Page 1 Powered Studio Monitoring Subwoofer User’s Guide...
- Page 3 2. Basics & Installation ........................4 Unpacking / Handling ..............................4 Connection ................................. 4 Comments .................................. 6 3. Technical Data..........................6 Rear Panel .................................. 6 4. General Information ........................8 ESI - Copyright © 2008 Revision 1, December 2008 www.esi-audio.com...
-
Page 4: Basics & Installation
SW10K eXperience 1. Introduction Congratulations on your purchase of the ESI SW10K eXperience. A subwoofer is an essential ingredient for many monitoring setups. Although many studio monitors such as our nEar04, nEar06, nEar05 eXperience or nEar08 eXperience provide sufficient bass frequency response, adding a SW10K eXperience subwoofer will help you to provide a better picture of the low frequencies in your mix. - Page 5 SW10K eXperience TRS balanced / unbalanced connection Connect male side of TRS balanced or unbalanced cable to the TRS inputs of SW10K eXperience – as show on the picture on the right. Make sure the power cable is connected as well. Satellite speaker connection If your source device has its own base management, you would typically connect the satellite speakers directly to them rather than to SW10K eXperience.
-
Page 6: Technical Data
SW10K eXperience Comments Please make sure to not place any obstacles that may block the flow of air or that could generate sound reflections (especially highly reflective material including glass or metal) in front of the speakers. Also, don’t put plants in pots on top or too close to your monitoring speakers. 3. - Page 7 SW10K eXperience 1. XLR inputs – these connectors accept balanced XLR input connections. The XLR input is wired like this: INPUT SIGNAL XLR CONNECTIONS PIN 2 PIN 3 Shield PIN 1 2. TRS inputs – these jacks accept TRS input connections, either balanced or unbalanced. For balanced connections, a 3-conductor TRS plug is necessary.
-
Page 8: General Information
GmbH. Other product and brand names are trademarks or registered trademarks of their respective companies. Correspondence For technical support inquiries, contact your nearest dealer, local distributor or ESI support online at www.esi-audio.com. Disclaimer All features and specifications subject to change without notice.
