- Page 1 SW10K SW10K SW10K SW10K SW10K • Professional Reference Sub-Woofer Monitor • User’s Manual www.esi-pro.com...
- Page 2 PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE NOTE: Some ESI products are equipped with dual or multi-voltage transformers (which are indicated on the back panel). Before you plug in the power cord, please check the AC voltage selector on the back panel of this product and make sure the voltage selector is set correctly.
-
Page 3: Table Of Contents
Contents Contents ............................3 Introduction ..........................4 SW10K Features.......................... 5 Subwoofer........................5 Enclosure ........................5 Network & POWER AMPLIFIERS ................5 Installation ........................... 5 Precautions........................5 Exterior Features......................6 1) BALANCE A......................... 6 2) Balance B........................6 3) Mute Control........................7 4) Power LED &... -
Page 4: Introduction
Thank you for choosing SW10K, powerful sub-woofer monitor speaker for professional studio applications and higher level home entertainment. ESI has been building excellent reputation for digital interfaces and near Field monitor speaker manufacturer. Now, after long research and development, SW10K is born to change the concept of reference sub-woofer monitoring. -
Page 5: Sw10K Features
SW10K Features 1. S UBWOOFER Subwoofer unit is 10inch in diameter with mineral filled polypropylene cone with high temperature voice coil and damped rubber surround. It is designed to deliver balanced subwoofer response. Polypropylene is used to react against the input signal accurately and to deliver even minimal input precisely minimizing distortion. -
Page 6: Exterior Features
Connection Connect L&R XLR balanced or TRS balanced / unbalanced input of SW10K to the corresponding pre-amp, computer or game console outputs. 2. E XTERIOR EATURES 1) B ALANCE Connect Male side of XLR Balanced Cables to the balanced inputs and balanced output to left satellite speaker. -
Page 7: Mute Control
Note: Assure that the power switch is turned off and Volume control is to minimum before connecting cable. 3) M ONTROL This connector allows you to connect a expression pedal that you can use to mute the subwoofer sound. This is helpful if you want to make A/B comparison of the sound with and without subwoofer and you can quickly control it with a simple pedal. -
Page 8: Phase Switch
6) P HASE WITCH The purpose of this control is to match the phase of satellite cut off frequency to the phase of the upper frequency limit of the Subwoofer. Adjust the Phase control to make the maximum sound pressure at cross over frequency in order to make sure Subwoofer and Satellites are in phase at cross over frequency. -
Page 9: Position Of The Subwoofer In The Studio
Connect the Professional Audio Console Subwoofer output to either L or R Input of SW10K through XLR or TRS connector. b. Connect SW10K Left and Right Inputs to Professional Audio Console without Bass Management. Professional Audio Console (Without Base Management) Output-L Output-R Input Input-L... -
Page 10: Technical Specifications
Technical Specifications - Type: Powered Subwoofer -Subwoofer Driver: 10" black paper cone with high temperature voice coil and damped rubber surround. - Frequency Response: 30Hz - 180Hz, Adjustable 50Hz – 180Hz - Amplifier Power: 100W@100Hz, 4 ohm, 0.1% THD - Dynamic Power: 120W - S/N Ratio: >100dB below full output - Input Connectors: 2 x XLR R/L Balanced Input Connector 2 x TRS Balanced/ Unbalanced Input Connector... -
Page 11: End User Warranty
All such returns must be shipped to EGOSYS, Inc. headquarters in Seoul, Korea (or US Office). In the event that ESI determines that the product requires repair because of user misuse or regular wear, it will assess a fair repair or replacement fee. - Page 12 If necessary, consult an experienced radio/television technician for additional suggestions. Correspondence For technical support inquiries, contact your nearest dealer, local ESI distributor or ESI directly at: EGOSYS, Inc. 6-9, Yongmoon-dong, Yongsan-gu Seoul, KOREA, 140-832 www.esi-pro.com...
-
Page 13: Safety Instruction
