x Stack
To add an entry into the DNS Relay Static Table, simply enter a Domain Name with its corresponding IP address and click Add
under the Apply heading. A successful entry will be presented in the table below, as shown in the example above. To erase an
entry from the table, click its corresponding

DNS Resolver

The DNS Resolver provides a solution to translate the domain name to an IP address for application on the switch itself.

DNS Resolver Global Settings

This window is used to configure the DNS resolver state and name server timeout.
To view this window, click Administration > DNS Resolver > DNS Resolver Global Settings, as shown below.
The following fields can be set:
Parameter
DNS Resolver State
Name Server
Timeout (1-60)
Click Apply to implement changes made.

DNS Resolver Static Name Server Settings

When adding a name server, if one primary name server exists in the static name server table and a new primary name server is
added, the existing primary name server will be changed to a normal name server. If the added primary name server's IP address
is the same as an existing normal name server's IP address, the existing normal name server will be changed to a primary name
server, but won't add new name server. When no primary name server is specified, the first configured name server will
automatically change to become the primary name server. If the deleted name server's IP address is the same as one of the existing
name servers' IP addresses, regardless of whether a normal name server or primary name server, the name server will be deleted.
To view this window, click Administration > DNS Resolver > DNS Resolver Static Name Server Settings, as shown below.
Figure 2 - 105 DNS Resolver Static Name Server Table window
®
DGS-3400 Series Layer 2 Gigabit Ethernet M anaged Sw itch
under the Delete heading.
Figure 2 - 104 DNS Resolver Global Settings window
Description
Use the pull-down menu to enable or disable the DNS resolver on the Switch. The default is
Disabled.
Enter the maximum time waiting for a response from a specified name server. The range is 1
to 60 seconds. The default value is 3.
90
