System Log Save Mode Settings - D-Link DGS-3427 - xStack Switch - Stackable Product Manual

x Stack
Facility
UDP Port (514 or
6000-65535)
Status
To set the system log server configuration, click Apply. To return to the System Log Host window, click the
Log Servers link.

System Log Save Mode Settings

This window may be used to choose a method for which to save the switch log to the flash memory on the Switch.
To view this window, click Administration > System Log > System Log Save Mode Settings, as shown below.
The following parameters can be configured:
Parameter Description
Save Mode Use the pull-down menu to choose the method for saving the switch log to the Flash memory.
There are three options:
Time Interval – Configure a time interval by which the switch will save the log files.
On Demand – Only save log files when manually telling the Switch to do so. Go to Save
Services > Save Changes to manually save log.
On Trigger – Save log files to the Switch every time when a log event occurs on the Switch.
Minute(s) When Time Interval is selected in Save Mode, set a time between 1 and 65535 minutes in the
field. The default value is 1 minute.
Click Apply to implement the changes. Click Save Log Now to immediately save log files currently on the Switch.
®
DGS-3400 Series Layer 2 Gigabit Ethernet M anaged Sw itch
are Emergency, Alert, Critical, Error, Warning, Notice, Informational, Debug, All and Level.
The default severity is Emergency.
Some of the operating system daemons and processes have been assigned Facility values.
Processes and daemons that have not been explicitly assigned a Facility may use any of the
"local use" facilities or they may use the "user-level" Facility. Those Facilities that have been
designated are shown in the following: Bold font means the facility values that the Switch
currently now.
Numerical Facility
Code
0 kernel messages
1 user-level messages
2 mail system
3 system daemons
4 security/authorization messages
5 messages generated internally by
syslog line printer subsystem
7 network news subsystem
8 UUCP subsystem
9 clock daemon
10 security/authorization messages
11 FTP daemon
Type the UDP port number used for sending Syslog messages. The default is 514.
Choose Enabled or Disabled to activate or deactivate.
Figure 2 - 32 System Log Save Mode Settings window
Numerical Facility
Code
12
13
14
15
16
17
18
19
20
21
22
23
38
NTP subsystem
log audit
log alert
clock daemon
local use 0 (local0)
local use 1 (local1)
local use 2 (local2)
local use 3 (local3)
local use 4 (local4)
local use 5 (local5)
local use 6 (local6)
local use 7 (local7)
Show All System
