User Manual
Your Phone
This section introduces you to the hardware of the device.
No.
1 Earphone jack
2
3
Earpiece
4
Touch screen Display screen.
5
6
P-sensor
7
Light sensor
G1315│ 1
Items
Functions
Use a headset for hands-free
conversation or listening to
music.
• Press and hold for several
seconds to turn the phone
on or off.
Power
• To set your phone to the
sleep mode, press the
power button briefly. Press
again to turn on the display.
The source of music and
voice.
• Power status notification.
LED
• Other notification. (New
message / Missed call).
The screen will turn off
automatically when taking the
device close to face on call.
Adjust the brightness of the
screen according to the
environment.
Advertisement
Table of Contents
Related Manuals for Gigabyte GSmart G1315
Summary of Contents for Gigabyte GSmart G1315
- Page 1 Your Phone Items Functions This section introduces you to the hardware of the device. Use a headset for hands-free 1 Earphone jack conversation or listening to music. • Press and hold for several seconds to turn the phone on or off. Power •...
- Page 2 Items Functions • Go back to Home Screen. Home • Press and hold to bring up recent activities. Press to view the options of Menu the menu. Connect to the website or find Search features in the phone. Return Return to the previous page. Sound Receiver.
- Page 3 Items Functions Press upwards or downwards to increase or decrease the Volume volume. Slide down the key fully to enter vibrate mode. You can insert your Micro 16 Micro SD Slot SD card. • Tap to activate the camera. • In Camera/Camcorder Camera key mode, press to take a photo or video.
-
Page 4: Installing Or Uninstalling The Sim Card, Battery, And Memory Card
Installing or uninstalling the SIM Card, 2. Please move your fingertip into the slot . Battery, and Memory Card To remove the back cover 1. Please turn over your phone with the back cover facing up. G1315│ 4... - Page 5 3. Stay your palm close to the back cover. Then To install the SIM card pull the back cover with your fingertip to remove Insert the SIM card. Make sure the gold contacts are facing down and the cut-off corner is facing towards the battery slot.
- Page 6 To remove the SIM card To remove the battery 1. Remove battery. Use your fingertip to lift the battery, and then, remove it. 2. Use your finger to slide the SIM card from the card slot. Battery Your phone comes with a rechargeable battery. Battery life varies depending on the network, used applications, and the type of connections attached to your phone.
- Page 7 To replace the back cover 2. With your right and left thumbs, press the middle of the 1. Please insert the hook on the bottom of the back cover. back cover into the slot of the phone. G1315│ 7...
- Page 8 3. Then, press the top of the back cover until click into Memory card place. You will need a microSD card to store photos, music, videos, and other data. To install the memory card 1. Insert the memory card with the gold contacts facing down.
-
Page 9: Charging The Battery
To remove the memory card 1. For safe removal, tap Application Drawer > Settings > SD card & phone storage > Unmount SD card. 2. Push the memory card down to eject it from the slot. Charging the Battery When you take your phone out from the box for the first time, the battery is only partially charge. -
Page 10: Notification Led
2. A pop-up window appears, and then, tap Power will endanger you. off. • Do not set the volume to its maximum with a 3. Select OK to confirm. headset as it may damage your hearing. • The following instructions are only provided with To set your phone to the sleep mode the original headset of the original manufacturer: To set your phone to the sleep mode, press the power... -
Page 11: The Home Screen
• If you are having a call Icons Descriptions conversation, press and Tap to launch Application Drawer hold the button to end the Tap and hold it to review the five call. home screens at the same time. • When you receive an incoming call, press and Tap to launch Phone. - Page 12 Wi-Fi Network is Speaker is on. activated. GPRS is in Battery is full. progress. EDGE is in Battery is low. progress. Battery 3G is in progress. Battery is very low. HSDPA is in Battery is charging. progress. Connection Portable Wi-Fi No network signal / hotspot is No SIM card...
-
Page 13: Android Manager
Synchronization Procedure Alarm. 1. Connect your device to your PC with the USB cable. 2. After you connect your device to your PC with a USB Event notification. cable, USB Manager will pop up. Tap PC Sync on your phone. Notification Missed call. -
Page 14: Usb Manager
music. can use your phone as a modem. Application: Allows you to manage the downloaded 4. Charge Only: Tap Charge Only on your phone to applications. start charging. Files: Allows you to organize and to manage files in both of your PC and your device. Install USB Driver Sync: Allows you to synchronize the following items: 1. - Page 15 Size 3.5” WCDMA/HSDPA 900 / 2100 MHz Resolutions 320 x 480 HVGA Connectivity Size GPS/AGPS Dimensions 113.5 x 61.22 x 13.28 Wi-Fi IEEE 802.11 b/g (L x W x T) Bluetooth Bluetooth 2.1 + EDR Weight 118 grams with battery Micro USB 2.0 Power 3.5 mm stereo audio...
- Page 16 NOTE: 1. Only ONE SIM card exist at one time when making phone call or internet browsing. 2. Network supporting: (a). SIM 1: 3G (WCDMA) (b). SIM 2: 2G (GSM) If this document is modified, please download the latest version on GSmart’s official website. You can download the user manual on GSmart’s official website also.
