Your Phone
This section introduces you to the hardware of the device.
No.
Items
1
Earphone jack
2
Power
3
Earpiece
4
Touch screen
5
LED
6
P-sensor
7
Light sensor
G1310│ 1
Functions
Use a headset for hands-free
conversation or listening to
music.
• Press and hold for several
seconds to turn the phone on
or off.
• To set your phone to the
sleep mode, press the power
button briefly. Press again to
turn on the display.
The source of music and
voice.
Display screen.
• Power status notification.
• Other notification. (New
message / Missed call / New
Mail).
The screen will turn off
automatically when taking the
device close to face on call.
Adjust the brightness of the
screen according to the
environment.

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte GSmart G1310

Summary of Contents for Gigabyte GSmart G1310

  • Page 1 Your Phone Items Functions This section introduces you to the hardware of the device. Use a headset for hands-free Earphone jack conversation or listening to music. • Press and hold for several seconds to turn the phone on or off. Power •...
  • Page 2 • Connect USB cable to PC as a • Go back to Home Screen. modem / USB mass storage. Home • Press and hold to bring up Micro USB port • Connect USB cable and the AC recent activities. adapter to charge the battery. Press to view the options of Menu menu.
  • Page 3 Items Functions Press upwards or downwards to increase or decrease the Volume volume. Slide down the key fully to enter vibrate mode. You can insert your Micro Micro SD Slot SD card. • Tap to activate the camera. • In Camera/Camcorder mode, Camera Key press to take a photo or video.
  • Page 4 Items Functions The speaker of music and Speaker voice. Flash LED Help photo shooting. The camera on the back of the Camera device supports 5-mega-pixel photo and high-quality video. You need to open the cover to Back cover install or uninstall the battery and the SIM card.

  • Page 5: Installing Or Uninstalling The Sim Card, Battery, And Memory Card

    Installing or uninstalling the SIM Card, 2. Please move your fingertip into the slot located at the top of the back cover. Battery, and Memory Card To remove the back cover 1. Turn over your phone with the back cover facing up. G1310│...
  • Page 6 3. Place your palm close to the back cover. Then pull the SIM card back cover with your fingertip to remove it. The SIM card contains your phone number, memory storage, and the details of the network service. To insert the SIM card Insert the SIM card.
  • Page 7 To remove the SIM card To insert the battery 1. Remove battery. Insert the battery. Make sure the contact of the battery is 2. Use your finger to slide the SIM card from the card slot. aligned with the connector on the battery slot. Battery Your phone comes with a rechargeable battery.
  • Page 8 To remove the battery Replace the back cover Use your fingertip to lift the battery, and then remove it. 1. Please insert the hook of the bottom of the back cover into the slot of the phone. NOTE: To ensure battery performance and avoid the risk of fire: •...
  • Page 9 2. With your right and left thumbs, press the middle of the 3. Then, press the top of the back cover until it clicks into back cover. place. G1310│ 9...

  • Page 10: Charging The Battery

    Memory card To remove the memory card You will need a microSD card for your photos, music, 1. For safe removal, tap Application Drawer > Settings > videos, and other data. SD card & phone storage > Unmount SD card. 2.

  • Page 11: Turning The Phone On Or Off

    To set your phone to sleep mode To set your phone to sleep mode, press the power button briefly. It will turn the display off. To turn the display on, press the power button briefly again. Notification LED Types Descriptions Solid red light Battery is charging.

  • Page 12: The Home Screen

    The Home Screen Types Descriptions • When you receive an incoming On Home screen, you can quickly access common call, press the button to answer features and view notifications of missed calls, received the call. If you are having a call messages, battery, and the status of the connection.
  • Page 13 Types Icons Descriptions Airplane mode. Volume is off when Call is in progress. you are on call. Vibration is on. Your call is on hold. Speaker is on. Volume Wi-Fi is connected. Earphone is Wi-Fi Network is connected activated. Headset is connected GPRS is in progress.

  • Page 14: Android Manager

    Android Manager The device is You can use Android Manager on your PC to synchronize connected to PC via data in your device. Please download Android Manager the USB cable. from GSmart’s official website to install it in your PC. New text message.

  • Page 15: Install Usb Driver

    Use Android Manager on your PC message to ask if you want to use data storage. It can Contacts: Allows you to back up contacts, as well as help you save the files. organize your contacts. 2. PC Sync: Tap PC Sync on your phone, your device will Messages: Allows you to edit and send messages.

  • Page 16: Specifications

    Specifications Up to 6.5 hours (It may vary depending on the System Information Talk time availability of local networks Platform Android 2.2 and the individual usage.) Qualcomm MSM 7225-1 at Processor Radio Band & Standard 528 MHz GSM/GPRS/EDGE 850 / 900 / 1800 /1900 MHz ROM 512 MB Memory WCDMA/HSDPA...
  • Page 17 NOTE: Specifications are subject to change without the prior notice. They may also vary in some regions. NOTE: only one SIM card exists at one time when making phone call or internet browsing. Network supporting: (a) SIM 1: 3G (WCDMA), (b) SIM 2: 2G (GSM).
