Intel® Server Board S3000PT TPS
0Fh Reserved
110h System Limit Exceeded (e.g. , voltage or
temperature threshold exceeded)
11h Asynchronous hardware timer expired and
issued a system reset
12h System configuration information
13h Hard-disk information
14h System reconfigured
15h Uncorrectable CPU-complex error
16h Log Area Reset/Cleared
17h System boot. If implemented, this log entry is
guaranteed to be the first one written on any
system boot.
18h-7Fh Unused, available for assignment by
SMBIOS Specification Version 2.3.4.
80h-FEh Available for system- and OEM-specific
assignments
FFh End-of-log. When an application searches
through the event-log records, the end of the
log is identified when a log record with this
type is found.
For more information about the EFI_STATUS_CODE_TYPE and EFI_STATUS_CODE_VALUE
definitions, refer to Intel Platform Innovation Framework for EFI Status Codes Specification ,
version 0.92.
Errors are also displayed on the BIOS Setup screen under the Server Management / View
Event Log menu in the following format:
EventName (times)
EventName is followed by the number of occurrences of the same event. The 'Time of
Occurrence' is the last time the event occurred.
6.2

Error Messages and Error Codes

The system BIOS displays error messages on the video screen. Before video initialization, beep
codes inform the user of errors. POST error codes are logged in the event log. The BIOS
displays POST error codes on the video monitor.
6.2.1

Diagnostic LEDs

During the system boot process, the BIOS executes several platform configuration processes,
each of which is assigned a specific hex POST code number. As each configuration routine is
started, the BIOS will display the POST code on the POST code diagnostic LEDs foun d on the
back edge of the server board. To assist in troubleshooting a system hang during the POST
process, the diagnostic LEDs can be used to identify the last POST process to be executed.
58
Time of Occurrence
Error Reporting and Handling
N
Y
N
N
N
N
N
Y
N
N
Y
Y
