2.5.4

SATA Configuration

While entering Setup, the BIOS automatically detects the presence of SATA devices. The
SATA Port items show Not Present if no SATA device is installed to the corresponding SATA
port.
SATA Mode [IDE Mode]
Allows you to set the SATA configuration.
[Disabled]
[IDE Mode]
[AHCI Mode]
[RAID Mode]
Serial-ATA Controller 0 [Enhanced]
This item appears only when you set the SATA Mode item to [IDE Mode].
[Disabled]
[Enhanced]
[Compatible]
Serial-ATA Controller 1 [Enhanced]
This item appears only when you set the SATA Mode item to [IDE Mode].
[Disabled]
[Enhanced]
S.M.A.R.T. Status Check [Enabled]
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor system. When
read/write of your hard disk errors occur, this feature allows the hard disk to report warning
messages during the POST. Configuration options: [Enabled] [Disabled]
2-20
Disables the SATA function.
Set to [IDE Mode] when you want to use the Serial ATA hard disk drives as
Parallel ATA physical storage devices.
Set to [AHCI Mode] when you want the SATA hard disk drives to use the
AHCI (Advanced Host Controller Interface). The AHCI allows the onboard
storage driver to enable advanced Serial ATA features that increases
storage performance on random workloads by allowing the drive to
internally optimize the order of commands.
Set to [RAID Mode] when you want to create a RAID configuration from the
SATA hard disk drives.
Disables the SATA function.
Set to [Enhanced] to support more than four SATA devices.
Set to [Compatible] when using Windows 98/NT/2000/MS-DOS. Up to four
SATA devices are supported under these oeprating syste.
Disables the SATA function.
Set to [Enhanced] to support more than four SATA devices.
