Intel Desktop Board DX58OG Technical Product Specification
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Front panel audio header
B PCI Express x1 bus connector
C PCI Express x1 bus connector
D Conventional PCI bus add-in card connector
E PCI Express x16 bus add-in card connector (Secondary)
F PCI Express x1 bus add-in card connector
G PCI Express x16 bus add-in card connector (Primary)
H Rear chassis fan header
I Intel 82X58 IO Hub (IOH)
J Back panel connectors
K Processor fan header
L Processor core power connector (2 x 4)
M LGA1366 processor socket
N DIMM 4 socket
O DIMM 1 socket
P DIMM 5 socket
Q DIMM 2 socket
R DIMM 6 socket
S DIMM 3 socket
T Main power connector (2 x 12)
U Front chassis fan header
V Intel 82801IJR I/O Controller Hub (ICH10R)
W SATA connectors (six 3 Gb/s interfaces (black) and two 6 Gb/s interfaces (blue))
X Chassis intrusion header
Y Piezoelectric speaker
Z Front panel USB headers (3)
AA Consumer IR receiver (input) header
BB Consumer IR emitter (output) header
CC BIOS Setup configuration jumper block
DD Front panel header
EE Auxiliary front panel power LED header
FF Post Code LED display
GG IEEE 1394a front panel header
HH Battery
II Onboard Reset button
JJ Onboard Power button
KK Base Clock Frequency Increase button
LL Base Clock Frequency Decrease button
MM Auxilliary chassis fan header
NN Status LEDs
12
