3 Opening and Closing the
HP NetServer

Removing and Replacing the Front Bezel

The front bezel has three clips that mount onto a hinge. The hinge is secured to
the front of the HP NetServer. You can swing the bezel open on its hinge, or
remove the bezel entirely.
To swing the bezel open, grasp it by the handle on its right edge and pull it open
to the left. This exposes the mass storage bay and the memory board bays.
To remove the bezel, pull it straight forward off the chassis. To replace the
chassis, press it back onto the chassis so that it snaps into place. See Figure 3-1.
Figure 3-1. Removing and Replacing the HP NetServer's Front Bezel
NOTE
HP NetServers installed in non-HP racks use a different front
bezel that mounts differently. For more infomation, refer to
the separate rack-mounting guide for third-party racks. It is
21
