- Page 1 User’s Manual Monochrome LCD Monitor It shall be assured that the final system is in compliance to IEC60601-1-1 requirements.
-
Page 2: Safety Symbols
This is a monitor intended for use in a medical setting. Copyright© 2004 EIZO NANAO CORPORATION. All rights reserved. No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, or otherwise, without the prior written permission of EIZO NANAO CORPORATION. -
Page 3: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS ... 4 1. INTRODUCTION ... 9 1-1. Features ...9 1-2. Package Contents...9 1-3. Controls & Connectors ...10 2. CABLE CONNECTION ... 12 2-1. Before connecting ...12 2-2. Connecting the signal cable ...13 3. ScreenManager ... 16 3-1. -
Page 4: Precautions
English PRECAUTIONS IMPORTANT! This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside the region to which it was originally shipped, the product may not perform as stated in the specifications. To ensure personal safety and proper maintenance, please read this section and the caution statements on the unit (refer to the figure below). - Page 5 WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your dealer for advice. Attempting to use a malfunctioning unit may result in fire, electric shock, or equipment damage.
- Page 6 English WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock. To disconnect the power cord, grasp the plug firmly and pull. Tugging on the cord may damage and result in fire or electric shock.
- Page 7 WARNING Do not touch a damaged LCD panel directly with bare hands. The liquid crystal that may leak from the panel is poisonous if it enters the eyes or mouth. If any part of the skin or body comes in direct contact with the panel, please wash thoroughly.
-
Page 8: Lcd Panel
English CAUTION Unplug the unit before cleaning it. Cleaning the unit while it is plugged into a power outlet may result in electric shock. If you plan to leave the unit unused for an extended period, disconnect the power cord from the wall socket after turning off the power switch for the safety and the power conservation. -
Page 9: Introduction
1. INTRODUCTION Thank you very much for choosing an EIZO Monochrome Monitor. 1-1. Features DVI (p. 40) Digital input (TMDS (p. 41)) compliant Resolution: 1 M pixels (1280 x 1024) Horizontal scanning frequency: 27 - 82 kHz (Digital input: 27 - 64 kHz) -
Page 10: Controls & Connectors
English 1-3. Controls & Connectors Front Control Panel SIGNAL 1 - 2 (1) ScreenManager Main Power Switch (3) SIGNAL 1-2 Signal selection button (Color/Monochrome) (4) AUTO Auto Adjustment Button (5) ENTER Enter Button Control Buttons (Left, Down, Up, Right) Power Button Power Indicator Green Orange... - Page 11 Rear Bottom (11) (9) Height Adjustable Stand (Detachable) (10) Security Lock Slot (11) SENSOR Serial Port (Mini DIN 8 pin) (for factory use) (12) Serial Port (Mini DIN 6 pin) (for factory use) (13) DVI-I Input Connector (14) USB Port (2 Downstream) (15) USB Port (1 Upstream) (16)
-
Page 12: Cable Connection
English 2. CABLE CONNECTION 2-1. Before connecting Before connecting your monitor to the PC, change the display screen settings (resolution p. 41) and frequency) in accordance with the charts below. NOTE When your computer and display support VESA DDC, the suitable resolution and the refresh rate are set by just plugging your display into the computer without any manual settings. -
Page 13: Connecting The Signal Cable
2-2. Connecting the signal cable NOTE Be sure that the power switches of both the PC and the monitor are OFF. Plug the signal cable into the connector at the rear of the monitor and the other end of the cable into the video connector on the PC. After connecting, secure the connection with the screw-in fasteners. -
Page 14: The Monitor
English [Signal selection] Please use the signal select button on the front panel. (1) The selection menu appears by pressing the button for more than 2 seconds. (2) Choose “Monochrome” by up and down keys. SIGNAL 1 - 2 Signal selection button (Color / Monochrome) Digital Input Signal Cable Signal Cable (FD-C04 / FD-C35 /... - Page 15 Plug the other end of the power cord into a power outlet. WARNING Use the enclosed power cord and connect to the standard power outlet of your country. Be sure to remain within the rated voltage of the power cord. Not doing so may result in fire or electric shock.
-
Page 16: Screenmanager
English 3. ScreenManager 3-1. How to use the ScreenManager Entering the ScreenManager Push the Enter button once to display the main menu of the ScreenManager. [Main Menu ] Making Adjustments and Settings (1) Select the desired sub menu icon using the Control buttons and push the Enter button. -
Page 17: Screenmanager Adjustments And Settings
3-2. ScreenManager Adjustments and Settings. The following table shows all the ScreenManager’s adjustment and setting menus. “*” indicates adjustments of analog input only and “**” indicates digital input only. Main menu Screen LUT Setting PowerManager Others Information Language Set to the “Normal” in case of using the monitor with the characteristic of panel original. -
Page 18: Useful Functions
English 3-3. Useful Functions Adjustment Lock Use the “Adjustment Lock” function to prevent any accidental changes. Locked function Unlocked function [How to lock] (1) Switch off the monitor’s power by the power button on the front panel. (2) Press on the Auto adjustment button while switching on the monitor’s power. [How to unlock] (1) Switch off the monitor’s power by the power button on the front panel (2) Hold down the Auto adjustment button once again and turn the power back on. - Page 19 Unlock function after calibration The calibration is available when using the specified optional calibration kit (p.37). After the calibration, the functions below are automatically locked. Locked function Brightness adjustment (including the adjustment by left and right buttons on the front panel) Range adjustment LUT Setting Signal selection button (Color / Monochrome)
-
Page 20: Adjustment
English 4. ADJUSTMENT 4-1. Screen Adjustment NOTE Allow the LCD monitor to stabilize for at least 20 minutes before making image adjustments. When connecting the digital graphics board, see page 23. Analog Input Screen adjustments for the LCD monitor should be used in suppressing screen flickering and also for adjusting the screen to its proper position. - Page 21 NOTE More precise adjustment is available for using the “Screen Adjustment program” utility software. It can be downloaded from the EIZO homepage (http://www.eizo.com/). Adjust by using <Screen> menu in the ScreenManager. (1) Vertical bars appear on the screen Use the <Clock> (p.40) adjustment.
- Page 22 English (3) The screen position is incorrect. Use the <Position> adjustment. The correct displayed position of the monitor is decided because the number and the position of the pixels are fixed. The <Position> adjustment moves the image to the correct position. Select <Position>...
-
Page 23: Digital Input
Adjust the output signal range (Dynamic Range) of the signal. Use the <Range Adjustment> (p.40) of <Screen> menu. This controls the level of output signal range to display the whole gradation (256 steps). [Procedure] Push the Auto adjustment button on the front panel while displaying the <Range Adjustment>... -
Page 24: Displaying Low Resolutions
English 4-2. Displaying low resolutions Using the <Screen Size> function in the <Others> menu enables to change the screen size of lower resolution (i.e. except 1280 x 1024). Enlarge the screen size when displaying a low resolution. Select the <Screen Size>. Select the <Screen Size>... - Page 25 English Set the brightness of the black area surrounding the displayed image. Set the <Border Intensity>. In the <Enlarge> mode or <Full Screen> mode, the outer area (border) is usually black. Select <Border Intensity> in the <Others> menu and adjust by using the right and left buttons.
-
Page 26: Power-Save Setup
English 4-3. Power-save Setup The <PowerManager> menu in the ScreenManager enables to set the power-save setup. NOTE • Do your part to conserve energy, turn off the monitor when you are finished using it. Disconnecting the monitor from the power supply is recommended to save energy completely. -
Page 27: Making Use Of Usb (Universal Serial Bus)
Required system environment • PC equipped with USB ports or another USB hub connected to the USB compliant PC • EIZO USB Cable (MD-C93) NOTE • The USB hub function may not work properly depending on the PC, OS or peripherals. - Page 28 English After setting up, the monitor’s USB hub is available for connecting USB compliant peripherals to the downstream ports of the monitor. Connecting Examples 5. MAKING USE OF USB (Universal Serial Bus) Monitor Keyboard Mouse Downstream Keyboard Printer Printer Downstream ports: Connect the cables from USB compliant peripherals such as a mouse, keyboard, etc.
-
Page 29: Attaching An Arm Stand
6. ATTACHING AN ARM STAND The LCD monitor can be used with an arm or stand by removing the tilt stand and attaching the arm stand to the LCD monitor. NOTE If you will use the arm or stand of other manufacturers, confirm the followings to the manufacturers before selecting. - Page 30 English Arm-stand 4 Mounting Screws: M4 x 15 (mm) BZn/Fe 6. ATTACHING AN ARM STAND...
-
Page 31: Troubleshooting
7. TROUBLESHOOTING If a problem persists even after applying the suggested remedies, contact an EIZO dealer. No picture problems Imaging problems Other problems USB problems Problems 1. No picture Indicator status: Off Indicator status: Green Indicator status: Orange Indicator status: Slowly flashing... - Page 32 English Problems 3. Display position is incorrect. 4. Screen image is smaller or larger than the actual screen images. 5. Vertical bars of distortion appear. 6. Horizontal bars of distortion appear. 7. Letters and lines appear blurred. 8. The slightly shadowed images or characters appear.
- Page 33 Problems 10. The screen is too bright or too dark. 11. Afterimages appear. 12. The screen has defective pixels (e.g. slightly light or dark). 13. Fingerprints remain on the screen. 14. <Smoothing> cannot be selected. 15. “Locked!” message appears and the adjustment controls are not available when pressing the control buttons.
- Page 34 If the problem is solved by doing this, contact an EIZO dealer. The power button of the APPLE keyboard does not operate if it is connected to the EIZO USB Hub. Please connect the keyboard directly with the PC. Refer to the instruction of the PC for details.
-
Page 35: Cleaning
8. CLEANING Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime. NOTE Never use thinner, benzene, alcohol (ethanol, methanol, or isopropyl alcohol), abrasive cleaners, or other strong solvents, as these may cause damage to the cabinet or LCD panel. -
Page 36: Specifications
English 9. SPECIFICATIONS LCD Panel Viewing Angle Dot Pitch Horizontal Scan Frequency Vertical Scan Frequency Resolution Dot Clock (Max.) Gray Scale Display Area Power Supply Power Consumption Input Connector Analog Input Signal (Sync) Analog Input Signal (Video) 0.7Vp-p/75 Positive Digital Input Signal Analog Signal registration Plug &... - Page 37 Classification of medical device: Class I Analog input Color VESA DPMS Normal Disable Menu Size: Normal, Menu Off Timer: 45 seconds Landscape English EIZO RadiCS GX2 EIZO RadiForce BNC Adaptor BI00FM 9. SPECIFICATIONS English mm (inches) Digital input DVI DMPM...
-
Page 38: Pin Assignment
English Pin Assignment DVI-I Connector 1 2 3 4 5 6 7 8 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 Pin No. Signal TMDS Data2- TMDS Data2+ TMDS Data2/4 Shield DDC Clock (SCL) DDC Data (SDA) Analog Vertical Sync TMDS Data1-... - Page 39 Preset Timing Chart for Analog input Based on the signal diagram shown below 25 factory presets have been registered in the monitor's microprocessor. Mode VGA 640 × 480 VGA 720 × 400 Macintosh 640 × 480 Macintosh 832 × 624 Macintosh 1152 ×...
-
Page 40: Glossary
English 10. GLOSSARY Afterimage The Afterimage is particular to LCD monitors when the monitor screen is left on for a long period without use. The “Afterimage” can be removed gradually by changing the displayed image. Clock With the analog input signal display, the analog signal is converted to a digital signal by the LCD circuitry. - Page 41 The LCD panel consists of a fixed number of pixel elements which are illuminated to form the screen image. The EIZO G11-S display panel consists of 1280 horizontal pixels and 1024 vertical pixels. At a resolution of 1280 x 1024, all pixels are displayed as a full screen.
-
Page 42: Memo
English MEMO MEMO... -
Page 43: Canadian Notice
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class A digital device. - AC Cord Shielded Signal Cable (enclosed) This Class A digital apparatus complies with Canadian ICES-003.
