JumperFree Configuration

The items shown in this screen may be different due to the CPU you installed.
Main Advanced
Configure System Frequency/Voltage
Ai Overclock Tuner
CPU Ratio and Voltage:
CPU Ratio
CPU Over Voltage
VDDNB Over Voltage
HT Connector Info
HT Link Speed
HT Link Width
HT Voltage
Memory Timming and Voltage:
DRAM Frequency
DDR3 Memory Profile
DRAM Voltage
DRAM Timing/Driving Configuration
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
Scroll down to display the following items:
Chipset Voltage
NB Voltage
NB 1.8V Voltage
SB Voltage
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
Ai Overclock Tuner [Auto]
Allows you to select the CPU overclocking options to achieve the desired CPU internal
frequency. Select any of these preset overclocking configuration options:
Manual
Auto
Overclock Profile
Test Mode
The following two items appear only when you set the Ai Overclock Tuner item to
[Manual].
CPU Bus Frequency [200]
Displays the frequency sent by the clock generator to the system bus and PCI bus.
Use the <+> and <-> keys to adjust the FSB frequency. You can also key in the desired
FSB frequency using the numeric keypad. The values range from 200 to 600.
PCIE Frequency [100]
Use the <+> and <-> keys to adjust the PCIE frequency. You can also key in the
desired FSB frequency using the numeric keypad. The values range from 100 to 150.
3-12
BIOS SETUP UTILITY
Power Boot Tools
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Disabled]
[Auto]
[Auto]
[Auto]
[Auto]
Allows you to individually set overclocking parameters.
Loads the optimal settings for the system.
Loads overclocking profiles with optimal parameters for stability
when overclocking.
Allows you to set the overclocking parameter to 5%.
Exit
Select the target CPU
frequency, and the
relevant parameters
will be auto-adjusted.
Select Screen
←→
Select Item
↑↓
+- Change Field
F1 General Help
F10 Save and Exit
ESC Exit
Chapter 3: BIOS setup
