Sony SS-SR3000P Instructions

Speaker System
SS-SR3000
© 2013 Sony Corporation Printed in Malaysia
Standard Connection/Raccordement standard/
Conexión normal
Foot pads
Tampons de pieds
Almohadillas para las patas
4-460-835-11(1)
+
–
Amplifier
Amplificateur
Amplificador
English
For customers in the United States
Owner's Record
The model and serial numbers are located on the rear
of the unit. Record these numbers in the space provided
below. Refer to them whenever you call upon your Sony
dealer regarding this product.
Model No.
Serial No.
Connection
• Before connecting, turn off the amplifier to avoid
damaging the speaker system.
• This speaker system is driven best by an amplifier
or receiver rated as per the wattage indicated in the
specification section.
Note
Avoid driving the speaker system continuously with a
wattage exceeding the maximum input power of this
speaker system.
Precautions
• Do not attempt to open the enclosure or remove
speaker units. There are no user-serviceable parts
inside.
• Keep recorded tapes, watches, and personal credit
cards using magnetic coding away from the speaker
system.
• Periodically wipe the cabinet with a soft cloth. Do
not use any type of scouring powder, abrasive pad or
solvent.
Speaker Placement
Please note that room acoustics can often produce large
difference in the sound for small changes in speaker
placement.
• Set up your speaker system on a hard, flat place.
• Place the speaker system against a hard wall with
its back about 10 cm (4 in) away from a wall. The
proportion of bass increases as you move a speaker
closer to intersecting room surfaces (wall and wall,
etc.).
Attaching the foot pads
Be sure to attach the supplied foot pads to the bottom of
the speaker to stabilize the speaker and prevent it from
slipping.
Specifications
Speaker system Full range
Speaker units 70 mm (2 3/4 in), cone type
Enclosure type Bass reflex
Rated impedance 8 ohms
Power handling capacity Maximum input power:
100 watts
Sensitivity level 85 dB (1 W, 1 m)
Frequency range 150 Hz - 20,000 Hz
Dimensions (w/h/d) Approx. 110 mm × 170 mm ×
111 mm (4 3/8 in × 6 3/4 in ×
4 3/8 in) including front grille
Mass Approx. 0.9 kg (1 lb 16 oz)
Supplied accessories Speaker cord (1)
Foot pads (4)
Design and specifications are subject to change without
notice.
