SERVICE MANUAL
Ver. 1.0 2017.05
• SS-RT4 is Bar speaker in HT-RT4/RT40.
• SS-SRT4 is surround speaker in HT-RT4/RT40.
• All the units included in the HT-RT4/RT40 (SA-WRT4/WRT40, SS-
RT4/SRT4, remote control) are required to confi rm the operation
of SS-RT4/SRT4. Check in advance that you have all the units.
9-890-691-01
2017E81-1
© 2017.05
Photo: SS-RT4
Bar Speaker (SS-RT4)
Front L/Front R/Center speaker section
Speaker system
Full range speaker system, Bass refl ex
Speaker
40 mm × 100 mm cone type × 3
Dimensions (w/h/d) (approx.)
900 mm × 52 mm × 70 mm
Mass (approx.)
2.1 kg
Surround Speakers (SS-SRT4)
Speaker system
Full range speaker system, Bass refl ex
Speaker
65 mm cone type
Dimensions (w/h/d) (approx.)
80 mm × 1,070 mm × 70 mm
(projecting parts not included)
Mass (approx.)
2.7 kg
Design and specifi cations are subject to change without notice.
Sony Corporation
Published by Sony EMCS (Malaysia) PG Tec
SS-RT4/SRT4
Photo: SS-SRT4
SPECIFICATIONS
AEP Model
UK Model
E Model
Australian Model
