Hunter 23869 Installation And Operation Manual

Type a models
Hide thumbs Also See for 23869:

Advertisement

Quick Links

Download this manual See also: Installation Manual
For Your Records and Warranty
Assistance
Model Name: ____________________
Catalog/Model No.: _______________
Serial No.: _______________________
Date Purchased: __________________
Where Purchased: ________________
For reference also attach your receipt or a
copy of your receipt to the manual.
installation and
operation manual
for Hunter
Ceiling Fans
TYPE A Models
42825-01 • 05/17/07

Advertisement

loading

Related Manuals for Hunter 23869

Summary of Contents for Hunter 23869

  • Page 1 Hunter For Your Records and Warranty Assistance Ceiling Fans Model Name: ____________________ Catalog/Model No.: _______________ Serial No.: _______________________ Date Purchased: __________________ Where Purchased: ________________ TYPE A Models For reference also attach your receipt or a copy of your receipt to the manual.
  • Page 2 Before installing your fan, for your records and warranty assistance, record information from the carton and Hunter nameplate label (located on the top of the fan motor housing). Cautions and Warnings •...
  • Page 3 To install and use the accessories, follow the instructions included with each product. For quiet and optimum performance of your Hunter fan, use only Hunter speed controls. Low Profile Mounting fits close to the ceiling, recommended for ceilings less...
  • Page 4 • Drill holes for and install wood screws. • Identify and connect electrical wires. • Lift 40 pounds. If you need help installing the fan, your Hunter fan dealer can direct you to a licensed installer or electrician. Gathering the Tools You will need the following tools for installing the fan: •...
  • Page 5 Tighten the screws into the 9/64” pilot holes; do not use lubricants on the screws. Do not over tighten. Flat Washer 3” Wood Screw Steps 2-4 – 2-6 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 6 3-3. Install two locking screws through the holes in the side of the metal bracket to secure the square hanger. Motor Green Assembly Ground Wire Step 3-2 Green Ground Wire Step 3-3 #8-32 x 1” Screw Locking Screw 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 7 • The black/white wire from the fan to the black/white wire from the ceiling. 4-4. Push all wires and wire nuts back through the ceiling plate hole into Wire the outlet box. Connector 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 8 4-7. Spread the wires apart, with the grounded wires on one side of the outlet box and the ungrounded wires on the other side of the outlet box. 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 9 Fan Housing 5-3. Install the two remaining canopy screws into the holes in the fan housing and into the hanger bracket. Securely tighten all screws. Step 5-3 Canopy Screw 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 10 6 • Assembling the Blades Hunter fans use several styles of fan blade irons (brackets that hold the blade to the fan). 6-1. Your fan may include blade grommets. If your fan has grommets, Step 6-1 (Detail) insert them by hand into the holes on the blades.
  • Page 11 7 • Completing Your Installation With or Without a Multi Staked Light Fixture Your Hunter fan comes with an integrated light fixture assembly and an optional switch housing cap and plug button. This feature gives you the option of installing the fan with OR without the included light fixture.
  • Page 12 7-10. Install candelabra base light bulbs (60 Watt maximum each). Note: Glass shade style and number of lights may vary. Plug Connector Housing Detail Assembly Screw Thumbscrews Shade Bulb Steps 7-8 – 7-10 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 13 Install and tighten the two screws Speed you removed previously from the other switch housing. Switch 7-20. Carefully place the capacitors in the switch housing. 7-21. Continue with Step 7-6. 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 14 To Change Airflow Direction Turn the fan off and let it come to a complete stop. Slide the reversing switch on the fan to the opposite position. Restart fan. Reversing Switch 42825-01 • 05/17/07 • Hunter Fan Company...
  • Page 15 2. Tighten all blade and/or blade iron screws. If you need parts or service assistance, please call 888-830-1326 or visit us at our Web site at http://www.hunterfan.com. Hunter Fan Company 2500 Frisco Avenue Memphis, Tennessee 38114 42825-01 • 05/17/07 • Hunter Fan Company...
