Instruction Manual
DVD-R100
CA
CA
AK68-00427C(01)
www.samsung.ca

Advertisement

Table of Contents
loading

Related Manuals for Samsung DVD-R100

Summary of Contents for Samsung DVD-R100

  • Page 1 Instruction Manual DVD-R100 AK68-00427C(01) www.samsung.ca...

  • Page 2: Warning

    Warning This unit can be used only where the power supply is AC 120V, 60Hz. NOTE It cannot be used elsewhere. This DVD recorder is designed and manufactured to respond to the Region Manage-ment Information. If the Region number of a DVD disc does TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT not correspond to the Region number of REMOVE THE COVER(OR BACK).

  • Page 3: Precaution

    Exterior interference such as lightning and static Precaution electricity can affect normal operation of this recorder. If this occurs, turn the recorder off and on again with the POWER button, or disconnect and then reconnect the AC power cord to the AC power outlet. The recorder will operate normally.

  • Page 4: Disc Storage

    This unit can play back DVD-R discs recorded and finalized with a Samsung DVD video recorder. It may Audio CD not be able to play some DVD-R discs depending on the disc and the condition of the recording.
  • Page 5 DVD-RW (VR mode) This DVD Recorder can allow you to protect the - This is a format that is used for recording data on a contents of your discs, DVD-RAM or DVD-RW disc. as described below. You can repeat recording, editing, deleting, partial Cartridge-protected: deletion, creation of playlist, and etc.

  • Page 6: Table Of Contents

    Method 4 : Connecting to Component video input Contents jacks(Y,Pb,Pr) in 480p mode ........18 Step 4 : Connecting the Audio cable.......18 Method 1 : Connecting to your TV......18 Method 2 : Connecting to a stereo amplifier with Getting Started Getting Started analog input jacks............19 Warning ...............2 Method 3: Connecting to an AV amplifier with a...
  • Page 7 Reviewing Images Being Recorded (Time Slip)..35 Language Setting............61 Making a One Touch Recording (OTR) ....36 Audio Setting ............62 Setting a Timer Recording ........37 Video (Display) Setting ..........63 Flexible Recording (for Timer recording only)..38 Parental Control............64 Editing the Scheduled Record List ......38 Editing Editing Deleting the Scheduled Record List ......39...

  • Page 8: General Features

    High quality progressive scan General Features Progressive scanning provides high resolution and flicker free images. The 10-bit 54-MHz DAC and 2D Y/C Separating Circuitry provides the highest image playback and recording quality. (See page 18.) The DVD-R100 allows you to record and play high quality digital images on DVD-RAM/DVD-RW/DVD-R discs.

  • Page 9: Before Reading The User's Manual

    All rights reserved; No part or whole of this user’ s to another format. It should be noted manual may be reproduced or copied without the prior that the data of the disc may be lost written permission of Samsung Electronics Co. when changing formats. English -...
  • Page 10 Step 3 Step 6 Recording Finalizing & Playing on other DVD components There are two different recording methods, Direct To play your DVD on other DVD components, finalizing Recording and Timer Recording. Timer recording is may be necessary. First, finish all editing and recording classified as recording type : Once, Daily or Weekly or operations, then finalize the disc.

  • Page 11: Description

    Description Front panel 7 8 9 17 16 15 14 18 11 13 12 1. POWER 11. REC Turns the recorder on and off. Starts recording. 2. DV-IN 12. CH ( Connects external digital equipment with a DV jack. Selects TV channels. 3.

  • Page 12: Rear Panel

    Rear Panel The fan always revolves when the power is on. Ensure a minimum of 4” clear space on all sides of the fan when installing the product. 1. COMPONENT VIDEO OUT SELECT 5. COMPONENT VIDEO OUT Selects the Component video out mode(480i or Connects to equipment having Component video 480p).

  • Page 13: Tour Of The Remote Control

    Tour of the Remote Control 10. MENU Button Brings up the DVD recorder’ s setup menu. 11. ENTER/DIRECTION Buttons (UP/DOWN or LEFT/RIGHT Buttons) This button functions as a toggle switch. 12. RETURN Button Returns to a previous menu. 13. REPEAT Button Allows you to repeat a title, chapter, track or disc.

  • Page 14: Connecting & Setting Up

    Quick Overview Connecting & A Quick Overview presented in this guide will give you enough imformation to start using the recorder. Setting Up Step 1 : Unpacking This section involves various methods of connecting the DVD player to other external †...

  • Page 15: Step 1: Unpacking

    Method 1 : Antenna + DVD Step 1: Unpacking Recorder + TV : No Cable box You can record non-scrambled channels by selecting the channel on the DVD Recorder. Also use this Method if you watch channels without cable box. Accessory Check for the supplied accessories below.

  • Page 16: Tv : Cable Box With A Few Scrambled Channels

    ‘standard definition’ output. If there are questions regarding our TV set compatibility with this model 525p DVD player, please contact our customer service center at 1-800-SAMSUNG. The VHF/UHF RF OUT jack of this product sends only signals received through the antenna. It does not output audio/video signals.

  • Page 17: Jacks(Y,Pb,Pr) In 480I Mode

    Method 2 : Connecting to an Method 3 : Connecting to S-video input jack Component video input jacks(Y,Pb,Pr) in 480i mode Connect an S-video cable(not supplied) between the S-VIDEO OUT jack on DVD Recorder and S-VIDEO IN 1. Connect Component video cables(not supplied) jack on the TV (or AV amplifier).

  • Page 18: Method 4 : Connecting To Component Video Input

    Method 4 : Connecting to Step 4 : Connecting the Audio Component video input cable jacks(Y,Pb,Pr) in 480p mode Your TV must support progressive scan input to allow you to watch 480p video output. 1. Connect Component video cables(not supplied) between the COMPONENT VIDEO OUT jacks on There are several ways to connect your DVD Recorder.

  • Page 19: Analog Input Jacks

    Method 2 : Connecting to a stereo Method 3: Connecting to an AV amplifier with analog input jacks amplifier with a digital input jack If your stereo amplifier only has audio input jacks(L and If your AV amplifier only has a Dolby Digital or DTS R), use the analog audio out jacks.

  • Page 20: Step 5 : Connecting External Devices

    Method 2 : Connecting a Step 5 : Connecting external Camcorder to the LINE 2 jacks devices You can also use the LINE 2 IN jacks on the front panel of the DVD Recorder. You can record from connected equipment. When an input source is inserted into LINE 2 while viewing TV, the input will be switched to LINE 2 This allows you to connect your DVD Recorder to other...

  • Page 21: Step 6 : Connecting The Power Cord

    Step 6 : Connecting the Power Step 7 : Preparing the Remote Cord Control After all connections are complete, plug the power cord Install Batteries in the Remote Control in the wall outlet. Open the battery cover on the back of the remote. Insert two AAA batteries.

  • Page 22: Controllable Tv Codes

    PIONEER TV POWER +58,+59,+73,+74 RADIOLA TV POWER +06,+56 RADIOMARELLI TV POWER +57 TV POWER +45,+46 TV POWER +74 SABA TV POWER +57,+72,+73,+74,+75 SALORA TV POWER +74 SAMSUNG TV POWER +01,+02,+03,+04,+05,+06,+07,+08,+09 SANYO TV POWER +41,+42,+43,+44,+48 SCHNEIDER TV POWER +6 - English...

  • Page 23: Step 8 : Initial Setup

    Press a Number button to select the Step 8 : Initial Setup language. For ease of use, we recommend that you set up initial settings before using the DVD Recorder. 1. OSD Language Setup † 2. Clock Set If the language for the startup screen is not set, the settings may change whenever †...
  • Page 24 Select System using the …† buttons, then If your clock is set to the wrong time zone or press the √ or ENTER button. daylight saving, you can adjust these settings System menu will be displayed. without tuning off the Auto Clock Set function. No Disc System Clock Set...
  • Page 25 Daylight Saving Use the †…œ √ buttons to select the select the Yes, No or Automatic using the …† buttons Current Date and Current Time, and then then press the √ or ENTER button. press the ENTER button. Select Automatic to set the daylight saving When the current time is stored in memory and automatically then the set is powered off, the current time will...

  • Page 26: Channel Set

    3. Channel Set Select Signal Source(Antenna/Cable TV) using the …† buttons, then press the √ or ENTER button. Auto Channel Memory Select the item that matches the antenna connection You can set the Antenna/Cable TV settings you selected on pages 15~16( method 1,2 or 3). automatically.
  • Page 27 Press the √ or ENTER button. Manual Channel Set Channel Set will be displayed. No Disc Channel Set Manual Channel Set can be used after you have first selected Auto Channel Memory. Antenna/Cable TV : Cable TV √ √ Auto Channel Memory √...

  • Page 28: Setting Up The Audio Options

    4. Setting Up the Audio Options Select the sub menu(Digital Output or DTS) using the …† buttons, then press the √ or Allows you to setup the audio device and sound status ENTER button. settings depending on the audio system in use. Select the item that matches the audio connection you selected on pages 18~19( method 1,2 or 3).

  • Page 29: Setting Up The Tv Aspect

    5. Setting Up the TV Aspect Use the …† buttons to select the desired item(4:3 LetterBox, 4:3 Pan-Scan or 16:9 This allows you to set up the TV screen settings. Wide). Then press the √ or ENTER button. With the unit in Stop mode, press the MENU No Disc Video button on the remote control.

  • Page 30: Recording

    This section shows various DVD recording meth- This recorder can record on the following discs. ods. DVD-RAM DVD-RW DVD-R DVD-RWs and DVD-RAMs are rewritable. DVD-Rs are non-rewritable Compatibility between Samsung Recorder and Other Company’s Recorder Disc Types Recording Recording Finalizing Additional Recording in format...

  • Page 31: Recording Formats

    Recording Formats Recording Mode When you insert an unused disc, the following message Select one of four recording modes by pressing the REC appears; Since available functions differ depending on MODE button repeatedly while the unit is in Stop mode the disc type, select a disc that best fits your preferences.

  • Page 32: About Info. Key

    About INFO. Key Recording the current TV program you are watching Before you start The INFO function allows you to view the current status and progress of playback and recording. Check that the disc has enough available space for the Depending on the kind of disc and status, the displayed recording.

  • Page 33: To Pause Recording

    To pause recording Press the CH ( / ) or number ( buttons to select the current program you Press the REC PAUSE button to pause a recording in want to record. progress. Press the REC PAUSE button again to resume recording.

  • Page 34: Recording From External Equipment You Are

    Press the REC button. Recording from external equipment you are watching To pause recording Press the REC PAUSE button to pause a recording in progress. Press the REC PAUSE button again to resume recording. ( / ) You can switch channels by pressing the Before you start buttons while recording pauses.

  • Page 35: Reviewing Images Being Recorded (Time Slip)

    When the INFO. button is pressed again: Reviewing Images Being Information about playback will appear. Recorded (Time Slip) DVD-RAM(VR) Playing Info Name APR/04/2004 12:00 AM Title 15/15 Created Time APR/04/2004 12:00 AM Length - --:--:-- - Playing Time 00:02:05 Title Protection Not Protected APR 24 2004 SAT 12:00 AM...

  • Page 36: Making A One Touch Recording (Otr)

    To view the current status of the disc and progress of Making a One Touch Recording recording : Press the INFO. button, and the information about the disc will appear. (OTR) DVD-RAM(VR) Disc Info Disc Name Total Title Total Playlist Recordable Time 03:00 SP Protection...

  • Page 37: Setting A Timer Recording

    Source: The video input source (L1, L2 or DV), or Setting a Timer Recording the broadcasting channel you want to set a timer recording. When selecting channels to be recorded, the …† buttons on the remote control can let you select only the channels that have been memorized during Auto Scan.

  • Page 38: Flexible Recording (For Timer Recording Only)

    Press the …† buttons to select Scheduled The timer recording time may differ from Record List, and then press the ENTER or √ the set time depending on the disc and the NOTE button. overall timer recording status (for exam- ple, recording times overlapping, or when the previous recording ends within 3 min- DVD-RAM(VR)

  • Page 39: Deleting The Scheduled Record List

    Press the …† buttons to select the number Deleting the Scheduled Record of the timer recording you want to delete, and then press the ENTER button. List The Edit and Delete items are displayed. DVD-RAM(VR) Scheduled Record List Remaining Recording Time 01:08 XP Source Date Start...

  • Page 40: Recording The Scheduled Record List

    To stop Recording Recording the Scheduled Press the STOP( ) button, and the message that asks whether to end recording or not will be displayed. Record List Do you want to stop recording? When one of the scheduled recording times is up while the recorder is in power-OFF status, the recorder will be powered on and start recording automatically.

  • Page 41: Playback

    Before Playing Playback Read the following information before playing a disc. Region code (DVD-Video only) Both the DVD recorder and the discs are coded by region. These regional codes must match in This section introduces basic functions of playback order for the disc to play. If the codes do not and playback by disc type.

  • Page 42: Playing A Disc

    Place a disc gently into the tray with the This DVD recorder can only operate with disc’ s label facing up. discs that are compatible with DVD-RAM NOTE For DVD-RAM discs, insert the printed side facing up. Standard Version 2.0. Playback and/or recording may not work for some types of discs, or when specific Press the OPEN/CLOSE button to close the...

  • Page 43: Using The Disc & Title Menu

    Using the Search Functions Using the Disc & Title Menu Some type of discs contain a dedicated menu system that allows you to select special functions for the title, such as chapters, audio track, subtitles, film previews, information on characters, etc. Disc Menu Press the DISC MENU button to enter the disc menu of the disc.

  • Page 44: Slow Motion Play

    About ANYKEY Searching Chapters or Tracks During play, you can search quickly through a chapter or track. During play, press the button on the remote control. If you press the œœ button, it moves to the beginning of the chapter or track or The ANYKEY function allows you to easily search for a marker(DVD-RAM, DVD-RW(VR mode)).

  • Page 45: Using The Repeat Function

    If you want to move to a desired time to Using the Repeat Function help you find a scene. Press the ANY KEY button during playback. DVD-VIDEO 1/10 1/40 00:01:45 D 5.1CH Playing Repeatedly(Repeat Playback) MOVE CHANGE Using the REPEAT button Using the REPEAT button Press the …†...
  • Page 46 Press the REPEAT button repeatedly to select the Track or Disc you want to play Using the ANY KEY button Using the ANY KEY button repeatedly. Music Press the ANY KEY button. Repeat : Track Play Option : Normal 01. TRACK 1 00 : 52 01.
  • Page 47 - To return to normal playback - - To return to normal playback - Press the REPEAT button repeatedly to select Press the REPEAT(A-B) button repeatedly to Off. select Off. Press the CANCEL button to return to normal playback. When VCD2.0 is in Menu Off mode only, Using the ANY KEY button Using the ANY KEY button this function works.

  • Page 48: Selecting The Subtitle

    Selecting the Subtitle Selecting the Audio language Subtitle languages may not work depending on the disc Audio languages may not work depending on the disc type. This is only available during playback. type. This is only available during playback. Using the AUDIO button Using the AUDIO button Using the SUBTITLE button Using the SUBTITLE button...

  • Page 49: Changing The Camera Angle

    Changing the Camera Angle Zooming-In When a DVD-VIDEO contains multiple angles of a particular scene, you can select the Angle function. Press the ANY KEY button during playback This is only available during playback. or pause. Press the ANY KEY button during playback. DVD-VIDEO 1/10 1/40...

  • Page 50: Using Pip(Picture In Picture)

    Using PIP(Picture in Picture) To view the current status and progress of playback : Press the INFO. button. The PIP function allows you to view a sub screen together with the main screen. DVD-VIDEO Info Title 1/10 You can view TV while playing a DVD disc. Chapter 1/40 Playing Time...

  • Page 51: Using Bookmarks

    Using Bookmarks Playing Back a Bookmark (V mode) Press the MARKER button. Press the MARKER button during playback. Press the œ √ buttons to select a book- marked scene. Bookmark Bookmark MOVE SELECT RETURN MOVE PLAY CANCEL RETURN Press the ENTER button when the desired scene appears.

  • Page 52: Using Markers

    Using Markers Playing Back a Marker (VR mode) Press the MARKER button. Press the MARKER button. Press the œ √ buttons to select a bookmarked scene. Marker Marker SELECT RETURN MOVE PLAY CANCEL RETURN Press the ENTER or button to start Press the ENTER button when the desired playing from the selected scene.

  • Page 53: Playing An Audio Cd/Mp3

    The Buttons on the Remote Control Playing an Audio CD/MP3 Each disc has a variety of menu functions available. Playing an Audio CD(CD-DA) Insert an audio CD (CD-DA) into the disc tray. The audio CD menu appears and the tracks (songs) are played automatically.
  • Page 54 Playing a MP3 Disc The Buttons on the Remote Control Insert a MP3 Disc into the disc tray. The MP3 menu appears and the tracks(songs) are played automatically. Music Repeat : Off Play Option : Normal Straight from the heart 00 :22 ROOT Bryan Adams...
  • Page 55 Play Option Mode To Program Tracks You can register a maximum 30 tracks in the playlist. The Play Option can be used with an audio CD or MP3 in the Play or Stop mode. Press the ANY KEY button. Repeat Mode will be highlighted. Press the ANY KEY button.

  • Page 56: Playing A Picture Cd

    Press the …† œ √ buttons to select a Playing a Picture CD picture. JPEG Photo Index 6 / Slide Show ROOT / DSC01189 Page 2 / There are two types of Picture CD. One is a CD with MOVE SELECT RETURN only JPEG files.

  • Page 57: Playing The Title List

    Press the …† buttons to select Title List, and Playing the Title List then press the ENTER or √ button twice. The Title List screen is displayed. DVD-RAM(VR) Title List No. Title Length Edit 01 APR/19/2004 1 00:00:21 √ √ 02 APR/19/2004 1 00:00:03 √...
  • Page 58 Press the INFO. button once again. Then you can check Title List Screen Elements the information about the title under playback. DVD-RAM(VR) Playing Info Name APR/21/2004 11:50 PM CH11 Title 1/16 Created Time APR/21/2004 12:00 AM DVD-RAM(VR) DVD-RAM(VR) Title List Title List Length 00:07:43 LP...

  • Page 59: Settings & Adjustments

    Using the Setup Menu Settings & For ease of use, we recommend that you set up the initial settings before using the product. Adjustments With the unit in Stop mode, press the MENU button on the remote control. Menu items differ depending on the disc type.

  • Page 60: System Setting

    Select CM Skip Time using the …† buttons, System Setting then press the √ or ENTER button. Channel Set will be displayed. DVD-R(V) System Clock Set √ √ Channel Set √ √ CM Skip Time : 15 Sec √ √ Clock Set (See page 23) MOVE...

  • Page 61: Language Setting

    Use the …† buttons to select the desired sub Language Setting menu and press the ENTER or √ button. Audio Language: For the speaker sound. Subtitle Language: For the disc subtitles. Disc Menu Language: For the disc menu contained on the disc If you set the player menu, disc menu, audio and Player Menu Language: For the player menu of your...

  • Page 62: Audio Setting

    Select the sub menu(Digital Output , DTS or Audio Setting Dynamic Compression) using the …† buttons, then press the √ or ENTER button. Digital Output, DTS: see page 28 No Disc Audio Allows you to setup the audio device and sound status Digital Output : PCM √...

  • Page 63: Video (Display) Setting

    Select the sub menu(TV Aspect,…,Front Video (Display) Setting Display) using the …† buttons, then press the √ or ENTER button. TV Aspect: see page 29 Input Level Adjusts the black level of the input signal. This allows you to set up the TV screen settings. No Disc Video TV Aspect...

  • Page 64: Parental Control

    3D Noise Reduction (motion adaptive noise reduction) Parental Control No Disc Video TV Aspect : 16:9 Wide √ √ Input Level : Darker √ √ Black Level : 7.5 IRE √ √ 3D Noise Reduction : Off √ √ Front Display : Auto Dim √...

  • Page 65: Buttons On The Remote Control

    Enter the 4-digit password using the 0 to 9 About the Rating Level buttons on the remote control. Set a new password. No Disc Parental Control Select Rating Level using the …† buttons. Create the password No Disc Parental Control Password √...
  • Page 66 About the Change Password The 'Confirm the password.' message will be Select Change Password using the …† displayed. buttons. Enter your password again using the 0 to 9 buttons on the remote control. No Disc Parental Control Password : On √...

  • Page 67: Editing

    Editing This section introduces basic functions of DVD editing and explains both edit functions for the recording on a disc and edit functions for the entire disc. Title List Title refers to a recorded video and audio stream. Title List shows a list to help you select a title. Since the title list consists of the information on stream that is actually recorded, if one title is deleted, that title cannot be played again.

  • Page 68: Basic Editing (Title List)

    DVD-RAM(VR) Rename Basic Editing (Title List) A B C D E a b c d e f g h i F G H I J K L M N O k l m n o p q r s t P Q R S T U V W X Y n w x y...

  • Page 69: Locking(Protecting) A Title

    Locking(Protecting) a Title Press the œ √ buttons to select On, and then press the ENTER button. The key icon on the Follow these instructions to lock an entry to protect it information window for the selected entry from accidental deletion. changes to the locked status.

  • Page 70: Deleting A Section Of A Title

    Deleting a Section of a Title Press the …† buttons to select Delete, and then press the ENTER button. Follow these instructions to delete a section of a Title List entry. DVD-RAM(VR) Title List (VR mode) No. Title Length Edit 01 Drama 00:00:21 √...
  • Page 71 Press the ENTER button at the starting point. Press the …† buttons to select Delete, and The image and starting point time are displayed in the then press the ENTER button. section deletion starting point window. The selected section has been deleted. DVD-RAM(VR) Edit Title List DVD-RAM(VR)

  • Page 72: Advanced Editing (Play List)

    Press the ENTER button at the end point. Advanced Editing (Play List) DVD-RAM(VR) Make Scene Scene No. 001 Start Start 00:00:10 Creating a Playlist 00:10:00 Make New Playlist Return APR/19/04 12:00 AM Follow these instructions to create a new playlist entry 00:10:00 from a recorded title.

  • Page 73: Playing Entries In The Playlist

    Playing Entries in the Playlist Press the …† buttons to select Play, and then select the ENTER button. Follow these instructions to play the playlist entries. The playlist entries will be played. DVD-RAM(VR) Edit Playlist (VR mode) No. Title Length Edit 01 APR/23/2004/0 00:00:21 √...

  • Page 74: Renaming A Playlist Entry

    Renaming a Playlist Entry Enter the desired characters using the …† œ √ buttons. Follow these instructions to rename a playlist entry, i.e. to edit the title of a playlist entry. DVD-RAM(VR) Rename Dolphin (VR mode) A B C D E a b c d e f g h i F G H I J...

  • Page 75: Editing A Scene For The Playlist

    Editing a Scene for the Playlist Playing a Selected Scene Follow these instructions to edit scenes for a playlist. Press the arrow buttons to select the scene you want to play, and then press the ENTER (VR mode) button. The playlist entry to be played is selected. Press the PLAY LIST button.

  • Page 76: Enter Button

    Press the ENTER button at the end point of Modifying a Scene (Replacing a Scene) the scene. DVD-RAM(VR) Modify Scene Scene No. 001 Press the arrow buttons to select the scene Start you want to modify, and then press the ENTER button.
  • Page 77 You cannot move the selected scene to the Moving a Scene (Changing the Position of a Scene) position of the next scene, because the NOTE selected scene should be inserted before that position, which requires no action. Press the …† œ √ buttons to select the Depending on the kind of disc, the dis- scene you want to move (change the played screen may have a slight difference.

  • Page 78: Copying A Playlist Entry To The Playlist

    Copying a Playlist Entry to the Press the ENTER button at the end point of the scene. Playlist DVD-RAM(VR) Add Scene Scene No. 004 Using the PLAY LIST button Start Using the PLAY LIST button Start 00:00:15 00:00:15 Sclence Press the PLAY LIST button. Cancel APR/23/2004 06:43 AM 00:00:35...

  • Page 79: Deleting A Playlist Entry From The Playlist

    Press the MENU button after the operation Press the …† buttons to select Delete, and has finished. The menu screen will disappear. then press the ENTER button. DVD-RAM(VR) Edit Playlist No. Title Length Edit 01 Science 00:00:17 √ √ 02 Sky 00:00:06 You can create up to 999 scenes on one √...

  • Page 80: Disc Manager

    Enter the desired characters using the arrow Disc Manager buttons. DVD-RAM(VR) Rename Disc A B C D E a b c d e f g h i F G H I J Editing the Disc Name k l m n o K L M N O p q r s t P Q R S T...

  • Page 81: Disc Protection

    Disc Protection Formatting a Disc Disc Protect allows you to protect your discs from being Use these instructions to format a disc. The cartridge formatted or deleted due to unintended operations. write protect tab should be set to the unprotect position. The disc protect should also be cleared.

  • Page 82: Delete All Title Lists

    Press the …† buttons to select Disc DVD-RW Manager, and then press the ENTER or √ You will be prompted with the confirmation message ‘Choose the recording format for button. DVD- RW.’ DVD-RAM(VR) Disc Manager DVD-RW(VR) Disc Manager Disc Name √...

  • Page 83: Cartridge Protect Info

    Cartridge Protect Info Finalizing a disc Disc Protect allows you to protect discs from disc After you record titles onto a DVD-RW/DVD-R disc with formatting and program deletion due to unintended your DVD recorder, it needs to be finalized before it can operations.

  • Page 84: Unfinalizing A Disc (V/Vr Mode)

    You will be prompted with the message 'Do you want to Unfinalizing a disc (V/VR mode) finalize disc?'. If you select Yes, you will be prompted again with the message ' Disc will be finalized. Do you want to continue?' DVD-RW(VR) Disc Manager Disc Name...
  • Page 85 Press the œ √ buttons to select Yes, and then press the ENTER button. The disc is unfinalized. A DVD-RW can be finalized or unfinalized in Video mode. NOTE Finalize Unfinalize Mark DVD-Video(RW) DVD-RW(V) Additional recording, protection Operation Same as DVD-Video and deletion are possible.

  • Page 86: Additional Information

    Troubleshooting Additional If your product malfunctions, go through the checkpoints below before contacting a Samsung Information authorized service center. Power The input is displayed for a while when the power is turned on. The DVD recorder requires some time Checkpoint 1 to initialize and the input will be displayed for approx.
  • Page 87 Differences between Using REC PAUSE Button and Play mode settings are different from the settings Using Stop Button during Recording configured in the Settings menu. The disc does not support all selected Each press of the Stop button during Checkpoint 1 Checkpoint 1 functions.

  • Page 88: Timer Recording

    Video Sound No sound. The disc revolves, but no image or bad quality images are displayed. Are you watching a program in slow or Checkpoint 1 Check whether there is damage to or skip mode? Checkpoint 1 any foreign material on your disc. If you are playing a program at a speed other than normal speed, sound will not Some low quality discs may not play...
  • Page 89 Checkpoint 2 Turn your DVD recorder off and on. Checkpoint 3 If the problem still persists, contact a nearby Samsung service center. Point the remote control at the remote Checkpoint 1 control sensor on your DVD recorder. Allow for proper distance. Remove obstacles between your DVD recorder and the remote control.

  • Page 90: Specification

    Specifications Power requirements 120V AC, 60Hz Power consumption 35 Watts Weight 8.27 lb General Dimensions 16.9in(W) x 11in(D) x 2.7in(H) Operating temp. +41°F to +95°F Other conditions Keep level when operating. Less than 75% operating humidity 1.0 V p-p at 75 load, sync negative Video (1,2) S-Video input (Y: 1.0Vp-p, C: 0.286Vp-p at 75...

  • Page 91: Warranty

    Warranty LIMITED WARRANTY TO ORIGINAL PURCHASER Samsung Electronics Canada Inc.(SECA), warrants that this product is free from defective material and workmanship. SECA further warrants that if this product falls to operate properly within the specified warranty period and the failure is due to improper workmanship or defective materials, SECA will repair or replace the product at its option.
